Beside the common standard tools, SPT is developing different solutions to meet special and challenging applications. We invest time and resources and work together with customers to satisfy your needs.
Typically, die collets are used with square or rectangular die, however, SPT supplies custom die collet configurations, compatible with a large range of specific die or component geometry. For more unusual applications, we can offer a range of options for odd shaped die, modified vertical relief for die that need to be placed in packages near walls and even odd shaped die (see the Rhomboid shape in the picture below)
ASM, Alphasem, Amica, Assembly Tech, ESEC, ESC, Datacon, Delvotec, Air Vac, Dr Tresky, Foton, Hacker, Hughes, ISMECA, K&S, KME, Laurier, MRSI, Muehlbauer, Palomar, Quad, SEC (Semiconductor Equipment Corp), Shinkawa, Toshoko, Universal, West Bond, Viking Semicon and other die bonders.
Got a different manufacturers part or information ? No problem, we can offer equivalent parts, just contact us for a quote.
CONTACT US FOR CUSTOM PICKUP TOOL OPTIONSCustom and Special Pick-up Tools Datasheet
