RADIOMETERS

Changes in UV output by lamps used for curing inks, coatings and adhesives tend to occur gradually, remaining undetected until product failures are noticed. By the time the loss in the lamps physical properties has been discovered, extensive, costly waste may have been produced.

Some UV production variables may change drastically while others deteriorate over time. When an unacceptable decrease in lamp energy is observed, these variables should be checked individually until the cause is positively identified and corrected.

We have lots of different types of Radiometers available for all types of applications. If you need assistance, please do not hesitate to contact us where we  will be able to help narrow down the options and to find the most suitable units for your needs.

BELT STYLE RADIOMETERS

DOSE MEASUREMENT

GENERAL TYPE

PROFILER RADIOMETERS

SOLAR

LAMP MONITOR

CABLES DETECTOR TYPE

ONLINE MONITORING RADIOMETERS

PROBE STYLE RADIOMETERS

UV MONITORING LABELS

CURE TESTING

SPECIAL TYPES











BIG DIGIT PROBEMETER RADIOMETER

The Big Digit Light Probemeter possesses a wide range for measurements as high as 20,000 Ft Candles or Lux. It is able to detect 0.01 Ft Candle/Lux resolution for accurate low light level measurements. This unit features a remote light sensor on 46" (1.5 m) cable, built-in color and cosine correction for precise measurements, and the built-in CIE Spectrum Curve simulates “human eye” response for optimum light analysis.

M007-002 Probemeter
M007-006 Probemeter with NIST Certification


Big Digit Light Probemeter Datasheet


UV SENSORS CON-TROL-CURE

Visible and solar blind, CON-TROL-CURE® UV Sensors offer solid-state reliability for reading the spectral range from 185-400nm when building your own sensing device. Features the sensitivity approaching that of PMT and the ease of a silicon detector. Because of its flat response across the UV range and essentially zero response anywhere else, it can, in many cases, provide an excellent alternative to photomultiplier tubes and enhanced silicon detectors. Ideal for building your own UV sensing instruments.

M007-047 UV Sensors 185-260nm

M007-048 UV Sensors 260-400nm

M007-049 UV Sensors Driving Circle

M007-048 Control Cure Sensor Product Manual


DISKURE 4SCAN RADIOMETER

The Diskure™ 4Scan Radiometers are equipped with three UV sensors for individual measuring of UV-A, UV-B, UV-C, and Total UV. They are designed to measure and display UV Intensity (mW/cm²) and UV Dose (mJ/cm²) for each of the 3 UV ranges individually in the UV curing process. This allows you to determine not only total energy, but also how that energy is delivered (which intensity/dose at each UV range).

There are 4 models available. Each measures as stated above. The differences are:

Diskure 4Scan (M007-111): Base model

Diskure 4Scan-C (M007-112): Adds a USB comport. When connected to a computer via USB, the Diskure 4Scan-C is able to show, profile, and store a history of the measured results of the entire UV curing process as graphic charts in mW/cm² and mJ/cm².

Diskure 4Scan-T (M007-113): Adds a temperature sensor

Diskure 4Scan-TC (M007-114): Adds a USB comport and temperature sensor. When connected to a computer via USB, the Diskure 4Scan-TC is also able to show, profile, and store a history of the measured results of the entire UV curing process as graphic charts in mW/cm², mJ/cm², and °F.

SPECIFICATIONS:
Spectral Range: UV-A, UV-B, UV-C, Full UV
Max. Power Input: 0 to 5,000 mW/cm²
Display Range: 0 to 36,000 mJ/cm²
0 to 2,000 mW/cm²
Power source: 2 x long life 3.6 V Lithium Battery
Battery Useful Life:2,000 hrs
Max Temp.: 230°F / 110°C (up to 10 seconds), housing
shouldn’t exceed 113°F / 45°C
Dimensions:
Diameter: 5.5” (140mm)
Height: ½” (13mm)
Weight: 9 ounces (500g)

M007-111 Diskure 4Scan, Base model
M007-112 Diskure 4Scan-C Adds a USB comport
M007-113 Diskure 4Scan-T Adds a temperature sensor
M007-114 Diskure 4Scan-TC Adds a USB comport and temperature sensor.
M007-475 DISKURE 4SCAN (SERIES) Radiometer UV-3C-T with temperature sensor

M007-114 Diskure 4Scan-TC Instruction Manual


ILT-400 ILT-490 RADIOMETER

ILT400 Profiling Belt Radiometer
New solid-state detector and ultra-stable amplifier technology along with rechargability combine to give lower noise, greater speed, and higher accuracy at a price below any precision belt radiometer sold today.
New solid-state detector and ultra-stable amplifier technology for lower noise, greater speed, and higher accuracy.
Built-in rechargeable batteries with included charger means less downtime.
Graphically displays the performance of each lamp and reflector in your system. A stored reference plot allows you to compare, on-the-spot, the current performance of the system with the base line. The information is provided instantly. and allows the operator to see the uniformity of the illumination.
Size: 12.7 x 111 x 161 mm (0.5" x 4.4" x 6.3")
Currently available in UVA, UVV (UVA/Vis), and BAV (UVB/UVA/Vis) models.

ILT490 Belt Radiometer



Features:
NIST – traceable calibration
Measurement spectrum matches industry standard IL390C (ILT490) and IL290 (ILT490C)
Built-in re-chargeable batteries (includes A400 charger)
Integrated exposure (J/cm2)
Peak irradiance (W/cm2)
Intensity profile with autoscale
Baseline profile memory

The NEW ILT490 incorporates the measurement capabilities and exceptional performance criteria of the original IL390 and IL290 UV Curing Light Bug, with the improved features of the ILT400, including profiling, graphing, cost reduction, rechargeable batteries and A400 charger.
The ILT490 works with many lamp options from Iron doped, H and D type lamps, as well as standard UV sources.
The ILT490 all in one Belt radiometer, comes in two versions: the ILT490 broadband UV for 250-400 nm, and the ILT490C UVC for 205-345 nm. (see graph below) Special ”O” software is available for low light level applications for 1 mW/cm2 to 2.5 W/cm2 with profiling at 10 mW/cm2 available at no additional cost.

The best just keeps getting better

Specifications
• Measurement Range: 1.00 to 20 W/cm2
• Exposure: 1 mJ/cm2 to 20 J/cm2
• Temperature: 100 to 500 (Case temperature)
• Irradiance PROFILE: 20 mW/cm2 to 20 W/cm2
• Accuracy: Typically better than + 6%
• Cosine Receptor: Integrating sphere
• Display: 4 Digits
• Display Graphics: Resolves 5% of full scale (peak irradiance)
• Size: 12.7 x 111 x 161 mm (.5” x 4.4” x 6.3”)

M007-097B ILT-490 RADIOMETER
M007-097C ILT-490C RADIOMETER

MICRO PUCK MINI RADIOMETER

The CON-TROL-CURE MICRO PUCK™ is a unique instrument that enables UV measurement in extremely difficult to access environments. Compact UV sensors make it possible to measure UV Dose even in most confined UV curing units. The MICRO PUCK system consists of two parts: a hand-held base unit with a display and a UV sensor. Simply plug the sensor into the base unit to view the measured results. The MICRO PUCK is available in four different measuring ranges: UV-A, UV-B, UV-C, or Full UV.

The MICRO PUCK comes complete with the sensor shape of your choice (round or rectangular) and in the UV range you desire. *NOTE: this model only works with the one sensor it ships with. If you need a multi sensor compatible base , choose the MICRO PUCK MULTI below.

While the MICRO PUCK can only read from the one sensor it ships with, the MICRO PUCK MULTI, can accommodate up to 8 sensors that read from the same base unit. This system can combine sensors from different UV spectral ranges, allowing for full spectrum, 3-D UV evaluation. The MICRO PUCK MULTI ships with 1 sensor in the shape of your choice (round or rectangular) and in the UV range you desire. For additional sensors (up to 8 total will work with this unit), simply select the type your need.

The sensors are available as either a rectangular or a round model. Both sensors work with both base units and are available in each of the 4 different UV measuring ranges.

SPECIFICATIONS:
Spectral Range: UV-A, UV-B, UV-C, or Full UV
Max. Power Input: 0 to 5,000 mW/cm²
Display Range: 0 to 1,999 mJ/cm² (standard) or
0 to 19,990 mJ/cm² (x10 type)
Power Source: 2 x 2,000 hrs 3.6 V Lithium Battery
Sensor Max. Temp.: 110°C (230°F) for up to 10 seconds
Dimensions of Reader: 5.5” x 3” x 0.4” (140 x 75 x 10mm)
Dimensions of Sensor:
Rectangular: 1.5” x 0.6” x 0.5” (40 x 15 x 12mm)
Round: Diameter 1.5” x 0.35” (40 x 9mm)
Round: (only M007-144) Diameter 1.5” x 0.25” (40 x 6mm)

M007-130 RADIOMETER :MICROPUCK FULL UV

M007-131 RADIOMETER :MICROPUCK UVA

M007-132 RADIOMETER :MICROPUCK UVB

M007-133 RADIOMETER :MICROPUCK UVC

M007-134R MICROPUCK RECALIBRATION

M007-135 RADIOMETER :MICROPUCK MULTI ALL UV

M007-136 RADIOMETER :MICROPUCK MULTI UVA

M007-137 RADIOMETER :MICROPUCK MULTI UVB

M007-138 RADIOMETER :MICROPUCK MULTI UVC

M007-139C MICROPUCK MULTICHARGER

M007-139R MULTISNSR RECAL2+

M007-140 RADIOMETER :SENSOR RECTANGULAR ALLUV

M007-141 RADIOMETER :SENSOR RECTANGULAR UVA

M007-142 RADIOMETER :SENSOR RECTANGULAR UVB

M007-143 RADIOMETER :SENSOR RECTANGULAR UVC

M007-144 RADIOMETER :SENSOR ROUND ALLUV

M007-145 RADIOMETER :SENSOR ROUND UVA

M007-146 RADIOMETER :SENSOR ROUND UVB

M007-147 RADIOMETER :SENSOR ROUND UVC

M007-506 RADIOMETER UV SENSOR ROUND

M007-507 RADIOMETER WIRELESS SENSOR T240

M007-508 RADIOMETER WIRELESS SENSOR T260

M007-509 RADIOMETER WRLF SENSOR T200

M007-510 RADIOMETER UV-MICROPUCK II

M007-511 RADIOMETER UV-MICROPUCK MULT

M007-512 RADIOMETER UV-SENSORS RECTANGULAR

M007-513 RADIOMETER UV SENSORS RECTANGULAR

M007-514 RADIOMETER UV SENSORS RECTANGULAR

M007-515 RADIOMETER WIRELESS SENSOR RECTANGULAR

M007-516 RADIOMETER WIRELESS UV SENSOR RT

M007-517 RADIOMETER WIRELESS SR. T1 50X13

M007-518 RADIOMETER WIRELESS SR T2 50X13

M007-519 RADIOMETER WIRELESS SR T3 50X13

M007-520 RADIOMETER WIRELESS SR T4 50X13

M007-521 RADIOMETER WIRELESS SR T5 50X13

M007-522 RADIOMETER WIRELESS SR T1 40X35

M007-523 RADIOMETER WIRELESS SR T2 40X35

M007-524 RADIOMETER WIRELESS SR T3 40X35

M007-687 RADIOMETER UV-INT MPUCK T5

M007-688 RADIOMETER UV MULTI PUCK T5

M007-689 RADIOMETER UV-V SENSOR RECTANGULAR



 M007-130 Micro Puck Radiometer Range Datasheet

 M007-130 Micro Puck Radiometer Range Manual




MICROLOG RADIOMETER

The CON-TROL-CURE UV-MICROLOG D™ is an extra thin (only 1/4” flat) self-contained UV data logging radiometer. This revolutionary unit is perfect for fitting into UV curing systems that bulkier models cannot. Contained in its sleek case is a sophisticated microprocessor that measures UV Intensity (mW/cm²), UV Dose (mJ/cm²), and Temperature.

The resulting measurements can be viewed 2 ways: either numerical results via the on-board display or downloaded through a USB computer link. Once the measured data is downloaded to a computer, you are then able to show a graphical representation of the UV Intensity Profile, the Peak Intensity, the Total Dose, and Temperature.

An Auto Off function shuts down the unit after one minute of inactivity to save battery energy. Special data acquisition software is included with each unit.

This unit is available with the LCD (M007-106), or without. The UV-Microlog 6 (M007-107), the unit that is without an LCD, connects to a computer to display its readings.

SPECIFICATIONS:
Spectral Range: UV 230 - 400 nm
Max. Power Input: 0 to 5,000 mW/cm²
Measuring Period: 30 sec.
Sampling Rate: 0.005 sec (200/sec)
Display: LCD, 2 lines x 16 digits
Power Source: 2 x long life 3.0 V Lithium Battery
Power Consumption: 20 µA
Battery Service Life: 2,000 hrs
Dimensions: 4.5" x 2.5" x 0.25" (117 x 64 x 6mm)
Weight: 3 ounces (85 g)

While on the conveyer belt, the UV-MICROLOG D can withstand 110°C (230°F) for up to 10 seconds. The temperature of the housing should not exceed 45°C (113°F).

M007-106 RADIOMETER UV MICROLOG D

M007-107 RADIOMETER UV MICROLOG 6



M007-106 Microlog D UV Radiometer Datasheet

M007-107 Microlog 6 UV Radiometer Datasheet



M007-262 RADIOMETER UV MICROLOG T1 UV-DIA

M007-263 RADIOMETER UV-A MICROLOG T2

M007-264 RADIOMETER UV MICROLOG T3

M007-265 RADIOMETER UV-B MICROLOG T4

M007-266 RADIOMETER UV-C MICROLOG T5

M007-533 RADIOMETER UV-T MICROLOG T1

M007-534 UV-T MICROLOG T2

M007-535 RADIOMETER UV-T MICROLOG T3

M007-536 RADIOMETER UV-T MICROLOG T4

M007-537 RADIOMETER UV-T MICROLOG T5

M007-538 RADIOMETER UV-MICROLOG 5X6 T1

M007-539 RADIOMETER UV-MICROLOG 5X6 T2

M007-540 RADIOMETER UV-MICROLOG 5X6 T3

M007-541 RADIOMETER UV-MICROLOG 5X6 T4

M007-542 RADIOMETER UV-MICROLOG 5X6 T5

M007-543 RADIOMETER UV-T MICROLOG 5X6 T1

M007-544 RADIOMETER UV-T MICROLOG 5X6 T2

M007-545 RADIOMETER UV-T MICROLOG 5X6 T3

M007-546 RADIOMETER UV-T MICROLOG 5X6 T4

M007-547 RADIOMETER UV-T MICROLOG 5X6 T5


PALM PROBE RADIOMETER

The PALM (P)roduction (A)mbient (L)ight (M)easurement Probe™ UV Radiometer is a process control instrument designed for measuring UV energy within inaccessible environments. It provides a safe, reliable measurement solution for UV-web and other applications.

The PALM Probe™ has an extremely wide dynamic range allowing it to measure very low (i.e. fluorescent bulbs) and very high (i.e. powerful UV curing systems) levels of UV. As the harsh physical conditions inside a UV curing chamber include extreme temperature variations, the PALM Probe is designed to withstand these conditions as well as protect the operator and instrument from damage or electrical shock. The light guide is constructed of steel alloy and coated with a non-conductive ceramic coating to insulate and protect the user from accidental shock. It is further isolated from the instrument body by a non-conductive Delrin block.

An input aperture at the tip of the PALM Probe light guide detects all wavelengths of ultraviolet, visible and infrared radiation. The light is directed down the light guide to the base of the instrument where a UV filter passes the UV light of interest to the photodetector. The LCD display toggles between watts, joules, and seconds during data collection and at the end of data collection.

ELECTRICAL SPECIFICATIONS:
• UV Range: 100µW/cm²-10W/cm²
• Spectral Response: UV-A 320-390nm, UV-B 280-320nm, UV-V 395-445nm
• Instrument Body Operating Temperature: 32 to 158°F (0°C to 70°C)
• Light Guide Temperature Resistance: 750°F (399°C) on a continuous basis; much higher for measurement length exposures
• Batteries: 2 “AA” alkaline batteries

MECHANICAL SPECIFICATIONS:
• Overall Length: 25.75” (65.4 cm)
• Probe Body Length: 7.5” (19.0 cm)
• Light Guide Length: 18.25” (46.4 cm)
• Weight: 21 oz (596 g)

M007-096A Palm ProbeTM UV-A

M007-096B Palm ProbeTM UV-B

M007-096L Palm ProbeTM Locator

M007-096V Palm ProbeTM UV-V

M007-690 RADM UV-PROBE INT T1
M007-691 RADM UV-PROBE INT T2



RADCHECK UV AND EB DOSE LABEL

By producing a linear, numerical benchmark of UV and EB system performance, the CON-TROL-CURE® Rad Check UV Measurement System provides repeatable evaluation results over extended periods of use. Incorporating a UV/EB-detection dosimeter and disposable UV and EB sensitive flexible test strips, the Rad Check system does not require outside calibration to ensure consistency.

Designed for web offset, flexo, 3-D screen and other systems incorporating inaccessible UV and high energy EB curing systems, the Rad Check test strip is the only UV dosage measurement device which can be passed completely through rollers, wrapped around cylindrical objects, or measure high EB dosages. Each test strip contains a UV/EB sensitive compound which is destroyed upon exposure to a UV light or EB energy source. After exposing the test strip, the density of the remaining compound can be measured by the Rad Check Dosimeter, which produces a numerical value reflecting energy received. This numerical value can be used to compare against jobs of similar characteristics for evaluating lamp degradation and system performance. 2 models available: the 800 for high intensity systems and the 300 for low intensity systems.

Test Strip Specifications:
• Dose Levels: Test Strip 300: UV: 0-300 mJ/cm²; EB: 0-35 Mrad
Test Strip 800: UV: 0-1400 mJ/cm²; EB: TBD
• Range: 320-380nm
• Durability: Approximately 6 months
• Packaging: 100 strips/pack

M007-078 Radcheck 300 Dosimeter
M007-079 Radcheck 300 Test Strips (pack of 100)
M007-079PS Power Adaptor
M007-081 Radcheck 800 Dosimeter
M007-082 Radcheck 800 Test Strips (pack of 100)

Radcheck Dosimeter Calibration Chart
M007-078 Radcheck 300 Dosimeter Datasheet
M007-079 Radcheck 300 Test Strip Datasheet
M007-079 Radcheck 300 Test Strip Manual
M007-081 Radcheck 800 Dosimeter Datasheet
M007-082 Radcheck 800 Test Strip Manual





SOLAR SERIES RADIOMETER

3 palm-sized precision instruments measure UV light for a variety of applications. The 6.5 and 6.0 measure via a Silicon Carbide (SIC) Photodiode packaged in hermetically sealed UV glass window cap. (the 5.0 uses GaAsP photodiode chip and UV filter.) Solar 5.0 measures total UV-A and UV-B (280-400nm) and is ideal for evaluating UV lamp intensity during its life span. Solar 6.0 measures UV-B (280-320nm) and is ideal for determining lamp UV-B intensity and acrylic transmission. Solar 6.5 measures environmental (outdoor) solar intensity (290-400nm, peaking between 297-310nm) and provides LCD readout in mW/m² SUV/25 (the WMO international standard for displaying erythemally weighted irradiance on a 1-15 scale).

Point the meter at the UV light source (leakage) and record reading. Calibrated to accuracy standards referenced to NIST.

5.0 SPECIFICATIONS:
Irrad. Range 0-199.9 mW/cm2 Total UV
Response 280-400 nm (UVB thru UVA)
Resolution 0.1 mW/cm²
Conv. Rate 3.0 Readings/Sec
Display 3.5 Digit LCD
Digit Size 0.4 inch high
Oper. Temp 32° F to 100° F
Oper. Humid. 5% to 80% RH
Accuracy ±5% REF.NIST
Dimensions (in.) 4.2L x 2.4W x 0.9D (in.)
Weight 4.5 OZ. (incl. batt.)
Power Source 9-Volt DC Battery
Lens UVT Acrylic .030
Diffuser Virgin Teflon .010

6.0 SPECIFICATIONS:
Irrad. Range 0-19.99 mW/cm² UVB
Response 280-320 nm
Resolution 0.01 mW/cm²
Conv. Rate 3.0 Readings/Sec
Display 3.5 Digit LCD
Digit Size 0.4 inch high
Oper. Temp 32° F TO 100° F
Oper. Humid. 5% TO 80% RH
Accuracy ±10% REF.NIST
Dimensions (in.) 4.2L x 2.4W x 0.9D (in.)
Weight 4.5 OZ. (incl. batt.)
Power Source 9-Volt DC Battery
Lens UV Glass
Diffuser Virgin Teflon .005

6.5 SPECIFICATIONS:
Peak sunlight response bandwidth: 290-298 nm
Total solar response: 290-400nm, Diffey
Display: 3 ½ digit LCD
Resolution: 0.1 UVI
Power Source: 9V DC battery
Accuracy: ±10% ref NIST

M007-054 Solar 5.0 Radiometer
M007-072 Solar 6.5 Radiometer
M007-073 Solar 6.0 Radiometer

M007-054 Solar Series 5.0 Radiometer Datasheet
M007-054 Solar Series 5.0 Radiometer Manual
M007-073 Solar Series 6.0 Radiometer Manual

SUNBURN & UVA INTENSITY METER

The Sunburning & UV-A Intensity Meter is capable of measuring the UV-A and UV-B spectrum. The meter shows the intensity of UV-B (also called SUV - Sunburning UV) in Minimal Erythemal Doses per Hour (MED/Hr), the accepted clinical measure for sunburn potential. The UV-A detector measures the range between 320-400 nm, displaying irradiance in mW/cm². This unit features a hold toggle that freezes the present reading, an auto shut off meter that turns the unit off after 8 minutes with near zero reading, and 3 ft extension cables for each detector.

METER SPECIFICATIONS:
UV-B (SUV) Readout range: 0 -19.99 MED/HR
UV-A Readout range: 0-19.99mW/cm²
Resolution: 0.01 MED/HR or mW/cm²
Operating temperature: 0 to +50°C
Power source: 9V alkaline battery

UV-B (SUV) Detector
Spectral Response 280-320nm
Operating Temperature -10°C to +60°C

UV-A Detector
Spectral Response 320-400nm
Operating Temperature -10°C to +60°C

M007-110 Sunburning UV Meter

UV POWER PUCK & UVICURE PLUS RADIOMETERS

The radiometers that first set the standard for the UV industry are now setting a new standard with advanced features and an easy to read display, multiple user selectable modes, and PC communication for data logging and trending capabilities, and process verification.
The new EIT Instrument Markets UVICURE Plus II and UV Power Puck II are advanced versions of the UVICURE Plus and UV Power Puck widely used throughout the global UV industry. With user selectable sample rates, these new instruments can be used for fast conveyor lines or slower lines, and measurements are compatible with other EIT products.

FEATURES:
• Measures UV Peak irradiance (microW/cm2, mW/cm2, W/cm2) and total energy density (microJ/cm2, mJ/cm2, J/cm2) of one spectral bandwidth (Uvicure Plus II) or 4 different bandwidths simultaneously (UV Power Puck II).
• New graph, data, and reference modes to provide choices in how to view the collected data
• Compact Size: 4.6" Diameter (117mm) x 0.5"H (13mm)
• Self-contained - battery-powered (user-replaceable AAA batteries)
• Unit communicates via cable to your PC

APPLICATIONS:
• Curing applications of inks, adhesives, solder masks, and epoxies (not for use in web press applications)
• Measure lamp performance
• Compares the efficiencies of different UV curing systems
• Compare any current reading to chosen baseline reference to compare your system over time
• Establish UV level for proper curing

Standard Features and Benefits Include:

• Easy to Use. One-Button Operation for On/Off and Run

• Easy to Read Data Display of All 4 Bands.
Data collected for all 4 bands on the UV Power Puck II is displayed simultaneously on screen in mW/cm2 and mJ/cm2 for quick and easy viewing by the operator. No need to toggle through all eight readings, one screen at a time. Soft buttons are used for function selections, and are indicated on the bottom of the display for easy operator selection and use.

• Standard EIT Multiple Bandwidths:
UVA (320-390nm), UVB (280-320nm), UVC (250-260nm), UVV (395-445nm)

• Dynamic Range
Standard unit - 10 Watt; UVA, UVB, UVV; 1 Watt UVC. Low Power unit -100 mW

• Setup Function
Provides user selectable instrument default modes for data analysis and comparison, screen, and operational settings.

• Reference Mode
Used for comparison between readings. Can be useful for system setup and troubleshooting. The user can store the selected UV reading in the radiometer as a base line or reference reading, then compare that reading to another. The radiometer will display both readings and indicate the percentage of change between readings. Data is displayed in mJ/cm2 and mW/cm2, and percentage.

• Graph Mode
A graph illustrating the collected UV irradiance and energy is displayed for each of the UV bands. Data is expressed in mW/cm2 vs. time. Graphs below illustrate both a one and two-lamp system.

• User Selectable Sample Rate
Smooth On Data: Compatible with previous Power Puck versions.
Smooth Off Data: Compatible with UV PowerMAP at over 2000 samples per second.

• Unit of Measure
The unit of measure is user selectable to provide ease of reading for operators. Display the data as you want to see it. Selections are: mJ/cm2, mW/cm2, J/cm2, W/cm2, µJ/cm2, µW/cm2

• Colorful, Easy to Read Display
Select low, medium, or high intensity for the graphical display.

• Communications Port
Serial communication protocol between unit and PC/PDA. Download collected data to a computer for statistical analysis and data logging, and process verification.

SPECIFICATIONS:
• Display: Easy to Read, Yellow Text on Black Background
• Accuracy: +/- 10%; +/- 5% typical
• Spectral Ranges (UV Power Puck® II): 4-channel simultaneous and continuous monitoring. 320-390nm (UVA), 280-320nm (UVB), 250-260nm (UVC), 395-445nm (UVV)
• Spectral Ranges (UVICURE® Plus II): 1-channel continuous monitoring. 320-390nm (UVA), 280-320nm (UVB), 250-260nm (UVC), 395-445nm (UVV)
• Spatial Response: Approximately cosine
• Operating Temperature: 0-75°C Internal temperature; tolerates high external temperatures for short periods (audible alarm indicates when temperature has exceeded tolerance)
• Time-Out Period: 2 minutes DISPLAY mode (no key activity)
• Battery: Two user-replaceable AAA Alkaline Cells
• Battery Life: Approx. 20 hours with display on
• Dimensions:  4.60 x 0.50 inches; 117 mm x 12.7 mm (D x H)
• Weight: 10.1 ounces (289 grams)
• Package Material: Aluminum, stainless steel
• Carrying Case Material: Cut polyurethane interior, scuff resistant nylon exterior cover
• Carrying Case Weight: 9 ounces (260 grams)
• Carrying Case Dimensions: 10.75 x 3.5 x 7.75 inches; 274 x 89 x 197 mm (W x H x D).

* Specifications are subject to change. EIT will not be responsible for discrepancies due to typographic errors.


M007-040 Radiom Power PuckTM
M007-040A UvicureTM Plus UV-A

M007-040B UvicureTM Plus UV-B

M007-040C UvicureTM Plus UV-C

M007-040V UvicureTM Plus UV-V



M007-040 Power Puck Radiometer Datasheet




UV-CUBE LOGGER

UV-Cube Logger

+ 3D measuring
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Various UV-ranges available
+ Permanent or „triggered“ measuring mode*
+ SD-Card Slot
+ Graphic chart on computer
+ LCD display

The UV-Cube Logger is a self-contained, high quality UV measuring instrument. It is designed to measure, record and display peak UV intensity and UV dosage in the UV curing process. In the standard version it is equipped with one UV sensor for the measuring of:

Full UV 230 – 410 nm

With this total UV band peak intensity and dose measuring, most of the measuring requirements of UV curing applications can be covered. Due to its UV sensor and the integrated microprocessor the UV-Cube Logger can measure, record and display the peak UV-intensity of the total UV spectrum (mW/cm2). Additionally, this UV-Cube Logger is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated as the total Integral of UV-dosage over the full UV spectral bands. Optionally it is available with an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C.
*This Datalogger features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The sensor is on one side of the unit, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. This UV-Cube Logger is additionally equipped with an SD-Card Slot and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2)

The UV-Cube Logger is available in six different measuring ranges:

UV-Cube Logger, Type 1 Diazo 350 – 460 nm
UV-Cube Logger, Type 2 UV-A 315 – 400 nm
UV-Cube Logger, Type 3 UV 230 – 410 nm (Standard)
UV-Cube Logger, Type 4 UV-B 280 – 315 nm
UV-Cube Logger, Type 5 UV-C 230 – 280 nm
UV-Cube Logger, Type 6 UV-V 395 – 445 nm
Also available with 2, 3 or 4 sensors and temperature measuring

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 1,000 charging cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to 113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-2C Cube Logger can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-377 RADM UV CUBE LOGGER T1
M007-378 RADM UV CUBE LOGGER T2
M007-379 RADM UV CUBE LOGGER T3
M007-380 RADM UV CUBE LOGGER T4
M007-381 RADM UV CUBE LOGGER T5

M007-377 UV Cube Logger Radiometer Datasheet


VERSAPROBE PRO RADIOMETER

The CON-TROL-CURE® VersaProbe Pro™ Radiometers are compact, high-tech, probe-style UV measurement devices. They measure UV Dose (mJ/cm²) and UV Intensity (mW/cm²).

The VersaProbe Pro can measure UV intensity and dose with the push of a button. Pressing the “Scan” button begins a 30 second cycle during which peak UV intensity and total dose are measured and recorded.

While exposed to the heat of UV curing lamps, the VersaProbe Pro’s metal-housed probe can withstand 110°C (230°F) for up to 10 seconds. The temperature of the housing should not exceed 45°C (113°F). An Auto Off function shuts down the unit after one minute of inactivity to save battery energy.

The VersaProbe Pro offers 4 models, each measuring a different UV wavelength:
• Full UV 250 - 410nm
• UV-A 315 - 400nm
• UV-B 280 - 315nm
• UV-C 230 - 280nm

SPECIFICATIONS:
Spectral Range: UV-A, UV-B, UV-C, Full UV
Max. Power Input: Sensor input to 5,000 mW/cm²
Display: LCD, 2 x 16 digits
Display Range: 0 to 36,000 mJ/cm²
Measuring Range: 0 to 2,000 mW/cm²
Sampling Rate: 0.005 sec (200/sec)
Recording Cycle: 30 seconds
Base Accuracy: ±5%
Power source: 2 x 3.6V Long Life Lithium Batteries
Battery Service Life: 2,000 hours
Dimensions (housing): 5.5"H x 3"W x 0.4"D (120 x 75 x 10mm)
Dimensions (sensor): 1.6"Diameter x 0.4"D (40 x 10mm)
Length of Sensor Cable: 40” (1m)
Weight: 6 oz (150 g)

M007-155 VERSAPROBE PRO:FULL UV

M007-155C VERSAPROBE PRO CHARGER

M007-156 VERSAPROBE PRO:UV-A

M007-157 VERSAPROBE PRO:UV-B

M007-158 VERSAPROBE PRO:UV-C

M007-159 VERSAPROBE PRO:UV-V

M007-159R Versaprobe Recalibration

M007-556 RADM UV-CP PROBE T1

M007-557 RADM UV-CP PROBE T2

M007-558 RADM UV-CP PROBE T3

M007-559 RADM UV-CP PROBE T4

M007-560 RADM UV-CP PROBE T5


IL1400 AND IL1700 RADIOMETERS

The IL-1700 Research radiometer is the most versatile current measurement instrument in the world. Designed specifically to measure photo detector current, the IL-1700 maintains unmatched linearity over a 10 billion to 1 dynamic range. This benchtop device is a powerful analytical tool

The portable IL-1400 combines the latest technical innovations in low level current amplification technology with microprocessor controlled simplicity. The onboard computer interrogates each "smart" detector for units, calibration and range information, automatically displaying a calibrated reading in the correct optical units. In addition to being user-friendly, the IL-1400 provides performance specifications unmatched by any other handheld radiometer on the market.

The IL-1700 and IL-1400 require at least one detector assembly to function. Detector/probe assemblies are avaialble for numerous standard and custom applications and can be purchased seperately. However, for general applications we have made ordering easy. Pre-packaged systems for the most common uses are now available including: Radiometer, probe, and applicable filters. No more guessing what system is right for you, we have done the work for you.

UV CURING
We offer the full line of International Light UV curing radiometers designed specifically for this application. All radiometers are calibrated to NIST standards in W/cm² and J/cm². For general purpose measurement requirements, the IL-1745 and IL-1445 are a perfect pre-packaged solution. However, in many graphic applications it is not possible to pass a monitor through the curing system. The RAMP probe has been designed to take spot irradiance measurements in confined environments. The IL-1747 and IL-1447 curing radiometers include the RAMP probe and appropriate detectors.

PHOTORESIST
Photoresist is an organic polymer which becomes soluble when exposed to ultraviolet light. It contains a light-sensitive substance whose properties allow image transfer onto a PCB board. Unique to these radiometer systems is the ability to autorange during exposure integrations. Proprietary floating current-to-current amplification technology permits autoranging without any gain changes, for real-time integration without data loss. Consult your photoresist manufacturer to determine whether the IL-1740 and IL-1440 in "A" (wide) response or "B" (narrow) response is appropriate for your application.

GERMICIDAL
UV irradiation is an effective method of killing a broad range of microbes. In essence, the UV radiation breaks the molecular bonds in the organism’s DNA. These Germicidal Radiometers use solar blind vacuum photodiodes and filters with band passes in accordance with the IES Luckiesh and DIN standards. For general Germicidal applications we recommend the IL-1771 or IL-1441.

CUSTOM
Both the IL-1400 and the IL-1700 systems can be further customized for the above applications and additionally configured for use in: Photometry, Radiometry, Phototherapy, Photobiology, Photostability, UV Hazard, Solar, Laser, and LED. Individual sensors, probes, and filters are available for adding to or upgrading your existing device.

M007-001 Radiometer IL1700

M007-001A Radiometer IL1745

M007-001B Radiometer Curing Lamp for IL1700

M007-001C Radiometer Photoresist A IL1700
M007-001D Radiometer Photoresist B IL1700

M007-001E Radiometer Germicidal IL1700

M007-001F Radiometer Customized IL1700



M007-017A Radiometer IL1400

M007-017B Radiometer Curing Lamp

M007-017C Radiometer Photoresist A for IL1400

M007-017D Radiometer Photoresist B IL1400

M007-017E Radiometer Germicidal IL1400

M007-017F Radiometer Customized IL1400

M007-017L Radiometer IL1400 LED



M007-001 IL1700 Radiometer datasheet

M007-001 IL1700 Radiometer manual

M007-017 IL1700 Radiometer datasheet

M007-017 IL1700 Radiometer manual


PROBES FOR IL1400 AND IL1700 RADIOMETERS

For use with the IL1400 and IL1700 Radiometers, the Right Angle Micro Probe takes short wave visible, and infrared measurements in hostile environments. It features a 90 degree viewing angle and a virtual sensing zone to quantitize in the actual radiation application plane. this low profile probe fits into a 4 mm opening and calibrates a wide range of curing systems.

The CON-TROL-CURE Right Angle Micro Probe is designed to perform measurements from 200 nm to 2,000 nm in 350 degree F temperatures. A machined quartz head incorporated in a pure fused silica fiber within a stainless steel sheath measures 4 mm x 4 mm x 12.7 mm.

Available in standard 1, 2, and 3 ft lengths, the CON-TROL-CURE Right Angle Probe can be installed into equipment permanently. The Right Angle Probe Adaptor is available for purchase separately.

M007-018B Radiometer Filter 1700 ND

M007-019B ILT-PROBE 005/WBS320/W

M007-021 Radiometer Probe Prb 1400 UVA

M007-022B Radiometer Probe Prb 1400 UVB

M007-023B Radiometer Probe Prb 1400 Actin

M007-024B Radiometer Probe Prb 1400 FLRES IR

M007-025B Radiometer Probe Prb 1400 FLRES H

M007-026B Radiometer Probe Prb 1400 ES Photo

M007-027B Radiometer Probe Prb 1400 BL Hazard

M007-028 Radiometer Probe Prb 1400 Photores

M007-029B Radiometer Probe Prb 1400 Mid UV

M007-030B Radiometer Probe Prb 1400 Deep UV

M007-031B Radiometer Probe Prb 1400 Germicidal

M007-032B Radiometer Probe Prb 1400 Erythem

M007-033B Radiometer Probe Prb 1400 Photom

M007-038B Radiometer Probe Prb 1400 UVA 7'CA

M007-039A Radiometer Thermo Paper

M007-039R Uvimap Recalibration



M007-052 Radiometer Probe Right Angle Micro for IL1400 / IL1700

M007-053 Radiometer Probe Adaptor Right Angle for IL1400 / IL1700

M007-055 Radiometer Probe Broadband UV for IL1400 / IL1700

M007-056 Radiometer Probe QNDS Filter for IL1400 / IL1700



M007-267 UV Sun Tan Probes for IL1400 / IL1700


DISKURE365 CONVEYOR RADIOMETER

The CON-TROL-CURE® DISKURE 365™ radiometer is our most economical pass-through radiometer for measuring UV radiation levels in high intensity, high energy curing environments. It is a UV dose measuring instrument small enough (5.5" / 140 mm diameter x .5" / 13mm height) for use in most UV curing ovens. A sensor on one side is exposed to the UV source and the other side contains a digital LCD which displays direct energy readings in mJ/ cm².

The aluminum housing can withstand exposure to oven temperature as well as intense vibration and shock. This durability makes the DISKURE 365™ ideal for measuring UV light energy in harsher environments such as photosensitive resist exposure systems, web processing equipment, print plate exposure systems and most UV curing ovens. Special filters and photodiodes absorb the visible as well as the IR portion of the light, so that measurements are made only on the required spectral region. After exposure, the radiometer’s LCD shows the total UV measured in mJ/cm² to which the unit was exposed.

SPECIFICATIONS:
• Weight: 1.1 lbs (500 g)
• Spectral Range: 250-410nm
• Accuracy: +/-10%
• Measuring Range: 0-5,000mW/cm²
• Heat Resistance: 158°F / 70°C (long exposure duration)
• Calibration Requirements: Every 12 months depending on use (average use: once a day; heavy: 3-5 times/day)

M007-091 DISKURE 365

M007-091R DISKURE 365 RECALIBRATION

M007-214 DISKURE 365 UV DIAZO

M007-215 DISKURE 365 UVA

M007-217 DISKURE 365 T4 UVB

M007-218 DISKURE 365 T5 UV-C



M007-092 Diskure 365 Radiometer Datasheet

M007-092 Diskure 365 Radiometer Manual


UV HAZARD METER (HANDHELD)

The UV HAZARD RADIOMETER (Ultraviolet Safety Meter) is a hand-held laboratory and industrial grade instrument that measures the UV radiation hazard to eyes and skin. A valuable safety tool for any industry that involves worker exposure to UV radiation. It is sensitive to ultraviolet radiation specified as hazardous in standards published by the American Conference of Governmental Industrial Hygienists. Those standards state that the total UV exposure in an eight-hour period should not exceed 3 milliJoules per square centimeter at 270nm. Other wavelengths have hazardous potential related to that of 270nm by the Spectral Weighting Function (see figure available in this menu). The Safety Meter monitors the integrated effect of all ultraviolet wavelengths from the light source.

M007-051 UV Hazard Meter

M007-051 UV Safety Hazard Meter Datasheet


UV LAMPLINE INTENSITY MONITOR

The state-of-the-art LampLine UV Intensity Monitors are electro-optic instruments designed for continuous on-line UV lamp monitoring. With continuous monitoring, a UV lamp's relative UV output is used to verify ongoing lamp performance. In each system, the LampLine UV Sensors (sold separately) are mounted permanently looking at the UV source.

With any LampLine monitoring system, the principle is the same. After installation, the user calibrates their system(s). When the lamp(s) are new and the irradiator(s) are clean, each monitor is set to 100%. The user then determines a Lower Limit percentage for the alarms and sets those. As a lamp degrades over time, the signal from the sensor is translated into a percentage of your original intensity setting as calibrated.

LampLine Multi-Channel Monitor:
This top of the line UV lamp monitoring system can monitor up to 4 lamps at a time on-line. However, it is cascadable, meaning more than 4 lamps may be monitored by adding additional Monitors, each interconnected so that any lamp dropping below threshold will set off an alarm. The front display shows the percentage of original output for any lamp being monitored.

LampLine Panel Mount:
This online monitoring system can be retrofitted to existing machinery or incorporated directly into equipment design. Each small monitor can be front-panel mounted so that the percentage of original output displayed on its LED can be constantly viewed and assessed by the user.

LampLine DIN Module:
The intent of this on-line system is to be able to monitor a multitude of lamps by snapping individual modules onto a rail which is normally mounted in the rear or side of the equipment. This system is available for use in integrated monitoring and control systems containing analog signal processing and shared display capability. DIN Modules do NOT have a display. Each rail mounted module allows for monitoring of a single UV lamp.

LampLine Sensors:
The sensors work with mercury vapor, electrodeless, deuterium, or any lamps which produce UV light. Sensors are ordered individually and are available in 250-260nm, 280-320nm, 320-390nm, or 395-445nm spectral responses. “Lamp On” detector indicates UV system is powered and lamp is running. Each sensor comes with a 10' cable (custom lengths are available).

M007-066A Lampline Panel Mount
M007-067A Lampline Multi-channel monitor
M007-068A Lampline DIN Module
M007-069B Lampline 365 Integrated Sensor
M007-069C Lampline 254 Integrated Sensor
M007-069D Lampline Sensor 280 to 320nm
M007-085 Lampline Sensor - Compact
M007-229 UV-PM 70 FP UP TO 70c

M007-066A Lampline Radiometer Range Datasheet

MICROCURE SLIM RADIOMETER

Directly affix this ultra-compact electro-optic device to almost any workpiece to accurately measure UV dosage under normal operating conditions. With a UV data collection instrument measuring only 1.30" (33 mm) by 1.0" (25 mm), the MicroCure™ is ideal for inaccessible curing environments such as web presses, bottle printers, container decorators, and compact disc coaters.

In web press applications, MicroCure passes through a UV curing station and is removed prior to reaching the print station location. Equipped with an adhesive-backed transport pad and pocket, the MicroCure adheres directly to any item including a web traveling vertically and/or while traveling at high speeds. In fact, MicroCure's high sampling rate of 2000 samples/second ensures that measurements taken at rapid web speeds will be accurate. Due to the instrument's extremely small surface area and very low profile (only 0.25" / 6.35 mm high), MicroCure can actually travel around idler rollers. For applications not requiring adhesion, the unit can be inserted directly into a can, cup or tube. Compact disc manufacturers who screen and/or coat CDs can put MicroCure into one of the CD "nests" when checking UV dosage against production parameters.

MicroCure is easy to use. There are no wires or connectors. Since it's always "on", there are no switches or buttons to push. Insert the unit into the DataReader and simply push the "Select" button to check the UV dosage. Available in 2 models: Standard 2W/cm² (90% intensity) or 10W/cm² (for heavy-duty microwave lamps).

M007-074 MicrocureTM with Data Reader 2W/cm2
M007-074A MicrocureTM with Data Reader 10W/cm2
M007-084 MicrocureTM replacement 2w
M007-084A MicrocureTM replacement 10w

M007-074 Microcure Data Reader Radiometer Datasheet
M007-074 Microcure Data Reader Radiometer Manual

R3 PROBE UV RADIOMETER

The CON-TROL-CURE® R3 Probe UV Radiometer is an affordable electro-optic UV measuring instrument. It is battery-operated, portable, extremely light-weight, and easy to use. It is designed to measure and display peak UV intensity in hard-to-reach curing chambers (such as narrow web presses) in order to evaluate system performance.
With the increasing use of narrow web presses and flexo printing technology, it has become necessary to create a method for measuring system performance. Degradation of UV lamps and parts can cause decreases in lamp output and create curing problems.
R3 stands for “Rapid Reach Radiometer”. The R3 Probe features an 18” extended probe allowing the operator to reach areas that might otherwise be inaccessible or dangerous to access. The probe is simple to use; just hold the unit’s base and position the sensor under the curing source. Quick readings allow the operator to measure performance of the system long before curing problems occur, without holding up the curing process.
The inside of a UV curing system can include extreme temperature variations and other harsh physical conditions. The CON-TROL-CURE® R3 Probe is designed to withstand these conditions while protecting the operator and instruments from electrical shock or damage. The 18” rigid light guide is completely made of non-conductive ceramic material to insulate and protect the equipment and the operator from damage or accidental shock.
The tip of the CON-TROL-CURE® R3 Probe can detect all ultraviolet, visible and infrared radiation wavelengths with its specially designed input aperture. It even detects into the UV-C spectrum down to 230nm. The sensor at the end of the arm directs the light down the arm to the base of the unit, there a UV filter passes the light of interest to the unit.
The CON-TROL-CURE® R3 Probe is an effective method of quantifying UV output. It provides the operator with instant feedback as to the performance of his UV curing system.

FEATURES
• A 9V battery block ensures extremely long life in excess of 100,000 readings.
• It can monitor UV intensities up to 9,990 mW/cm²
• Compact, Portable size
• Light-weight - Approx. 5 ounces
• 18” non-conductive ceramic probe
• The measurements taken can be viewed directly on the LCD display.

TECHNICAL DATA
• Spectral range: M007-108 UV-A 315-410NM; M007-109 UV FULL 230-400NM
• Max. Power Input 0 to 9,990 mW/cm²
• Display: LCD, 3 digits X 10
• Display range: 0 to 9,990
• Measuring range: 0 to 9,990 mW/cm²
• Power source: 9 V Block Battery
• Power consumption: 20 µA
• Battery service life: 2,000 hrs (100.000 Measurings)
• Dimensions: 6.25” (158 mm) x 1.6” (40 mm) x 1.3” (34 mm)
• Weight: Approx. 5 ounce (125 g)
• Length of light guide: Approx. 18” (45 cm)
• Overall length: Approx. 24.25”
• Operating temperature: 0 to 122° F / 0 to 50° Centigrade
• Base Accuracy: ± 5 % The maximum permissible temperature for the light guide is 400° Centigrade/ 750° Fahrenheit. The temperature of the housing should not exceed 122° F / 50° Centigrade.

Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions. CALIBRATION
Like most radiometers, in order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery.

M007-108 RADM:R3 UV-A 315-410NM

M007-108A UV-A RADIOMETER ONLY

M007-109 RADM:R3UVFUL 230-400NM

M007-109A UV FULL RADIOMETER ONLY

M007-200 R3 CERAMIC PROBE ONLY

M007-300 R3 POSITIONING SET



M007-108 R3 Probe Radiometer Datasheet
M007-108 R3 Probe Radiometer Manual


SILVER LINE RADIOMETER

The CON-TROL-CURE® Silver Line Radiometers are rugged, probe-style UV measurement devices. These simple-to-operate radiometers measure UV Intensity (mW/cm²).

The Silver Line radiometers have 2 resolution settings. The “x1” setting displays UV intensities from 0 to 19.99 mW/cm², while the “x10” setting displays from 0 to 199.90 mW/cm². The rugged metal-housed sensor is capable of withstanding high temperatures and moderate shock. While exposed to the heat of UV curing lamps, the Silver Line radiometer probe can withstand 110°C (230°F) for up to 10 seconds. The temperature of the housing should not exceed 45°C (113°F).

An Auto Off function shuts down the unit after one minute of inactivity to save battery energy.

The Silver Line series offers 4 models, each measuring a different UV wavelength:
• UV-A: 315 - 400nm
• UV-B: 280 - 315nm
• UV-C: 230 - 280nm
• Full UV: 230 - 410nm

SPECIFICATIONS:

• Max. Power Input: Sensor input to 1,000 W/cm²
• Display: LCD, 4 digits
• Range x1: 0 - 19.99 mW/cm²
• Range x10: 0 - 199.90 mW/cm²
• Base Accuracy: ±5%
• Power Source: 2 x 3.6V Lithium Battery
• Dimensions (housing): 5.5"H x 2.75"W x 0.5"D (140 x 70 x 13mm)
• Dimensions (sensor): 1.6"Diameter x 0.4"D (40 x 10mm) - 1m length
• Weight: 200 g

M007-150 Silverline Radiometer UVA

M007-151 Silverline Radiometer UVB

M007-152 Silverline Radiometer UVC

M007-153 Silverline Radiometer ALL UV



M007-191 Silverline Radiometer DIAZO UVV

M007-192 Silverline Radiometer UVA MTR SILVER



M007-204 Silverline Radiometer UV-V SIL Spare

M007-205 Silverline Radiometer UV-A Silver Spare

M007-206 Silverline Radiometer UV-B Silver Spare

M007-207 Silverline Radiometer UV-C Silver Spare

M007-208 Silverline Radiometer UV Silver Spare HD

M007-150 Silverline Probe Style Radiometer Datasheet


SPOT CURE METER (VU RADIOMETER)

The Spot Cure™ Meter is an easy, portable, and effective means of quantifying UV output. This self contained, electro-optic instrument is designed to measure and display the intensity emitted by a UV spot curing system.

It uses a special lithium battery stick for extremely long life-in excess of 100,000 readings. It measures UV intensity from 0-19.99W/cm². A measurement head which contains the optics is attached to one end of the cylindrical instrument. Light guide adaptors which fit into the measurement head are available to fit all size light guides. It can be configured to read one of the following UV transmission bandwidths: 250-260nm (UV-C), 280-320nm (UV-B), 320-390nm (UV-A), or 395-445nm (UV-V). Meets ISO-9000 requirements.

M007-041A Spot CureTM UV-A
M007-041B Spot CureTM UV-B
M007-041C Spot CureTM UV-C
M007-041V Spot CureTM UV-V

M007-041 Hand Held Spot Cure Radiometer Datasheet


UV POWER MAP & UV MAP PLUS RADIOMETER

The UV PowerMAP™ and the UV MAP Plus™ are both advanced measurement systems that measure and store UV energy, UV irradiance, and temperature information derived from their optics and thermocouple probes in UV curing processes. The UV PowerMAP simultaneously measures all 4 UV spectral regions (UV-A, UV-B, UV-C, and UV-V) while the UV MAP Plus only measures 1.

The information is transferred to a PC where it is presented in graph and data format for viewing and analysis. The information is characteristic of the same energy and irradiance that would be impinged on an actual work piece passing through the curing process. Variables such as reflector materials, reflector shapes, wavelength-specific reflector degradation and uniformity, and lamp focus can be documented.


FEATURES:
• UV PowerMAP measures peak power density and total energy density in 4 spectral regions: UV-A, UV-B, UV-C, and UV-V
• UV MAP Plus measures the peak power density and total energy density for any 1 spectral region
• Collection and storage of up to 1 million data points
• Collected data displayed in graphical and tabular forms in the PowerView™ software package
• PowerView enables an ultra-fast, user-adjustable sampling rate - up to 2048 samples/second – that ensures high resolution even at high speeds
• Detachable Optics Head - allows the use of different optics heads with the Data Collection Unit to minimize downtime during recalibration
• Type J thermocouple records temperatures from 0-500°C
• Low, narrow profile to allow access to most curing applications
• Rugged aluminum chassis and stainless steel case
• Unit Dimensions 3.50"W X 9.0"L X 0.5"D (8.89cm X 22.86cm X 1.27cm)
• Weight 20.2 ounces (570 grams)

The UV PowerMAP and UV MAP Plus systems are composed of a data collection unit, detachable optic measurement head, and PowerView software package. The units measure UV energy in J/cm² and UV irradiance in W/cm².

M007-087 UV Power MapTM
M007-087R Re-calibration For UV Power MapTM
M007-088A UV Power Map Plus TM UV-A
M007-088B UV Power Map Plus TM UV-B
M007-088C UV Power Map Plus TM UV-C
M007-088V UV Power Map Plus TM UV-V


M007-087 UV Powermap and Uvimap Advanced Profiling Radiometers datasheet

M007-087 UV Powermap and Uvimap Advanced Profiling Radiometers manual


UV PROFILER RADIOMETER

Shown above the UV-Data Sampler with built-in PDA display. View and analyze data without the need for download!

+ 2 channel
+ UV intensity mW/cm2
+ UV dose mJ/cm2
+ Temperature measuring
+ Pass-through data acquisition
+ Built-in sensors
+ 2x16 digits LCD Display
+ computer programmable
+ Parameter selection
+ Auto scale function
+ Free selectable Integral
+ Graphic charts on PC via ComPort
+ Result storing capability on PC via ComPort
+ Microsoft Evaluation Software
+ Auto off

The UV Data Sampler profiling radiometer system has been specifically designed to measure UV-radiation on high-end UV-curing printing market. Via ComPort, it is connected to a PC in order to pre-select parameters for the measuring cycle. After passage of the UV light source(s) the recorded data can be downloaded to a computer for further editing by Microsoft Evaluation Software. The measurement, integrating, and recording of data from all sensor channels takes place at user-defined intervals.


The UV-Profiler Radiometers are available in 6 distinct models:

The UV-Profiler-3000™ handheld system combines the power and convenience of a PDA with the analysis of a full featured radiometer. The UV-Profiler-3000 delivers a rapid profile of your UV curing system and displays the results via its onboard color viewing screen or it can be connected to a PC.

The UV-Profiler-3000 measures UV from 250nm to 410nm. Results are presented as UV Intensity (mW/cm²), UV Dose (mJ/cm²), and Temperature. The UV-Profiler-3000 is equipped with one UV sensor and one temperature sensor.

The TFT touch screen display shows the complete UV energy profile and offers zooming and auto scale functions. Peaks and Integrals are selectable on the screen and will be displayed in numerical format. The sampling rate is 50 milliseconds (20/second).

The UV-T Profiler series of radiometers is similar to the UV-Profiler-3000 in that it measures UV Intensity, UV Dose, and Temperature. But it differs in 2 main aspects. There is no onboard viewing screen. Results are accessed by connecting the unit to a computer. The other main difference is that the UV-T Profilers are available in 4 different UV ranges:

• Full UV: 230nm-410nm (M007-121)
• UV-A: 315nm-410nm (M007-122)
• UV-B: 280nm-315nm (M007-123)
• UV-C: 230nm-280nm (M007-124)

The UV-3C Profiler radiometer measures UV Intensity and UV Dose (not Temperature). The main difference between this unit and the UV-T models is that the UV-3C has 3 UV sensors. So it is able to simultaneously measure UV-A, UV-B, UV-C, and Full UV. As with the UV-T, the data is displayed only via a computer link.

The UV-3C-T Profiler radiometer is identical to the UV-3C but adds the capacity to measure Temperature. As with the UV-3C, the data is displayed via a computer link.

FEATURES:
• UV Energy Measurement
• 64 MB Memory
• UV Dose Measurement
• Auto-scale Function
• ComPort for Computer Downloads
• Microsoft ActiveSync Software

SPECIFICATIONS:
Spectral Range: Total UV (250nm to 410nm)
Max. Power Input: 0 to 5,000 mW/cm²
Display Range: 0 to 100,000 mJ/cm² / 0 to 2,000 mW/cm²

11150:
UV-2C Data Sampler:

M007-120 RADIOMETER :UV PROFILER-3000

M007-121 RADIOMETER :UVT PROFILR ALL UV : 230nm-410nm

M007-122 RADIOMETER :UVT PROFILER UVA : 315nm-410nm

M007-123 RADIOMETER :UVT PROFILER UVB : 280nm-315nm

M007-124 RADIOMETER :UVT PROFILER UVC : 230nm-280nm

M007-125 RADIOMETER :UV-3C PROFILER

M007-126 RADIOMETER :UV-3C-T PROFILER

M007-525 RADIOMETER  UVP 3000/2 PROFILER

M007-526 RADIOMETER  UVP 3000/2 PROFILER

M007-527 RADIOMETER UVP 3000/3C PROFILER


UVX RADIOMETER

NOTE: Radiometer (M007-043) sold separately. Probes (M007-044, 045 & 046) must be purchased individually.

The CON-TROL-CURE UVX Radiometer's unique simplicity makes its operation as easy and fool-proof as possible. Simply plug in 1 of the 3 remote interchangeable probes (254nm, 300nm, or 365nm), set the EXTERNAL ZERO ADJUST to read 00.0 on the LCD, and you're ready to measure. The probe is then placed in the UV environment and the intensity reading will be shown on the display. It continuously monitors its own power supply and informs when its voltage is too low for accurate readings.

A 3-foot shielded cable allows the placement of the probe in hard-to-reach locations. Full exposure is not necessary as accurate readings are still possible because each probe's cosine sensitivity is nearly perfect. Each sensor has a tripod mount which is built into the bottom of the probe. All 3 probes are calibrated for measurement in their own UV band. Calibrations are accurate to +/-2% and traceable to the National Bureau of Standards.

NOTE: BECAUSE OF ITS HEAT SENSITIVITY, THE UVX RADIOMETER IS NOT RECOMMENDED FOR USE WITH HIGH INTENSITY UV CURING SYSTEMS.

M007-043 RADIOMETER:UVX
M007-044 RADIOMETER PROBE UVX 365MN

M007-045 RADIOMETER PROBE UVX 300NM
M007-046 RADIOMETER PROBE UVX 254NM



M007-043 Ambient UV Radiometer Datasheet


UV-3C Microprocessor Integrator UV Measuring Instrument

The UV-3C ComPort Microprocessor Integrator is a self-contained, high quality UV measuring instrument.

It is designed to measure, record and display peak UV intensity, UV dosage in the UV curing process. It is equipped with three different UV sensors for the individual measuring of:

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm*
UV - 230 – 410 nm

With these three different UV-bands, most of the measuring requirements of UV curing applications can be covered. Due to its three different UV sensors and the integrated microprocessor the UV-3C ComPort can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV energy. Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UVB and UV-C or UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. Optionally it is available with an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C

*This Microprocessor Integrator features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm². The three sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle all measuring results can be scrolled through on the built in 2 x 16 digit LCD display.A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. This microprocessor integrator is additionally equipped with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2) and (°C/°F)

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
(or UV-V 395 – 445 nm)
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: LCD, 2 x 16 digits
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-3C ComPort Microprocessor Integrator can withstand max. 230° F /110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per
year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN
EN ISO / IEC 17025 with certificate

M007-176 RADIOMETER UV-MC INT UV-DIAZ

M007-177 RADIOMETER UV-MC INT T2 UV-A

M007-178 RADIOMETER UV-MC INT T2 UV

M007-179 RADIOMETER UV-MC INT T2 UV-B

M007-180 RADIOMETER UV-MC INT T5 UV-C



M007-176 UV-3C Microprocessor Integrator UV Radiometer Datasheet


NEW ADDITION UV-COMPORT INTEGRATOR DVD FOR PRODUCTION LINE

The UV-T ComPort Integrator DVD is a self-contained, high quality UV measuring instrument.

+ UV-intensity mW/cm2
+ UV-dose mJ/cm2
+ Temperature measuring °C/°F
+ Special design Æ 4.7“ / 120 mm with center hole
+ USB ComPort
+ Graphic chart on computer

It is specially designed to measure, record and display peak UV intensity, UV dosage and temperature in the UV curing process of CD and DVD production. In the standard version it is equipped with one UV sensor and one temperature sensor for the measuring of:
Full UV 230 – 410 nm
Temp 32° to 230° F / 0° to 110° C

With this total UV band measuring, extra temperature measuring and its special size and design it is particularly suitable to cover the measuring requirements of UV curing applications in CD and DVD production. Due to its UV sensor and the integrated microprocessor the UV-T ComPort Integrator DVD can measure, record and display the peak UV-intensity of the total UV spectrum (mW/cm2).

Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated as the total Integral of UVdosage over the full UV spectral bands. An extra sensor measures temperatures from 32° to 230° F / 0° to 110° C The two sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle all measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. This microprocessor integrator is additionally equipped with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2) and (°C/°F)

TECHNICAL DATA
Spectral range: UV 230 – 410 nm (Standard)
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 230° F / 0 to 110° C
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 hrs
Dimensions: Æ 4.7” (120 mm), height 1/4” (6,5 mm)
Weight: approx. 10,5 ounce (290 g)
Operating temperature: 32 to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-T ComPort Integrator DVD can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration with certificate.

M007-301RADM UV-COMPORT DVD T2

M007-302RADM UV-COMPORT DVD T3

M007-303RADM UV-COMPORT DVD T4

M007-304RADM UV-COMPORT DVD T5

M007-305RADM UV-3C COMPORT DVD

M007-306RADM UV+T CP DVD T1

M007-307RADM UV+T CP DVD T2

M007-308RADM UV+T CP DVD T3

M007-309RADM UV+T CP DVD T4

M007-310RADM UV+T CP DVD T5

M007-311RADM UV-3C-T CP DVD

M007-312RADM UV-2C CP INT DVD

M007-313RADM UV-2C CP INT DVD

M007-314RADM UV-2C CP INT DVD

M007-315RADM UV-2C CP INT DVD

M007-316RADM UV-2C CP INT DVD

M007-317UV-2C-T CP INT DVD

M007-318RADM UV-2C-T CP DVD

M007-319RADM UV-2C-T CP DVD

M007-320RADM UV-2C-T CP DVD

M007-321RADM UV-2C-T CP DVD

M007-677RADM UV-4C CP INT DVD



M007-301 UV Comport Integrator DVD and CD duplication radiometer and temperature measurement datasheet


NEW ADDITION SPECTROMETER



Spectrometer Accessories

+Evaluation Software Spectrasuite

+Fiber Optical Light Guide 2.0 SMA

+Reflection Measuring head for spectral reflection measuring with two SMA connections

M007-566 RADIOMETER MINI SPEC UV-VISION

M007-567 RADIOMETER SPECTROMETER 19

M007-568 RADIOMETER SPECTROMETER LOGGER

M007-569 RADIOMETER SPEC SOFTWARE

M007-570 RADIOMETER FIBER OP LT GUIDE

M007-571 RADIOMETER REFLECT HEAD SMA




NEW ADDITION UV-1200 COLOR RADIOMETER AND DOSIMETER

The UV-1200 Colour Radiometer + Dosimeter is a self-contained, high quality UV measuring instrument.


+ Choice of a combination of two different spectral ranges:
+ UV-A intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-B intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-C intensity mW/cm2 + UV-A dose mJ/cm2
+ UV-V intensity mW/cm2 + UV-V dose mJ/cm2
+ Big color graphic display
+ Numerical and graphical display
+ Permanent or „triggered“ measuring mode*

It is designed to measure and record UV intensity and UV dosage in the UV curing process. Measuring results are indicated both, graphically and numerically on a big colour display. It is equipped with two different UV sensors for the individual measuring of a combination of either:

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV - 230 – 410 nm

With these two different UV-bands many of the measuring requirements of UV curing applications can be covered. Due to its two different UV sensors and the integrated microprocessor the UV-1200 Colour Radiometer + Dosimeter can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV energy. Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B and UV-C or UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. Optionally it is available with an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C.

*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The two sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT colour display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. As an option, the UV-1200 Colour Radiometer + Dosimeter is available with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2) and (°C/°F)

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm, UV-V 395 – 445 nm
UV-B 280 – 315 nm, UV-C 230 – 280 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: TFT Colour Display, 45 x 34 mm (1.75” x 1.3”)
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: Æ 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° Celsius
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-1200 Colour Radiometer + Dosimeter can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-431RADM UV-1201 COL

M007-432RADM UV-1202 COL

M007-433RADM UV-1203 COL

M007-434RADM UV-1204 COL

M007-435RADM UV-1205 COLOR

M007-436RADM UV-1206 COLOR

M007-437RADM UV-1207 COLOR



M007-431 UV 1200 Colour Radiometer and Dosimeter Datasheet


NEW ADDITION UV-INT 126


Rectangular type UV-Integrator 115x60x13 mm

The UV-Integrator 126 is a high quality UV measuring instrument. It is used to measure UV energy of different light sources, especially on printing machines. It is ideal to ensure quality control of printing and drying processes.Small size, heavy duty pass-through Integrator . It is reliable and simple to use.The UV-Integrator 126 is available in five different measuring ranges:

UV-Integrator 126, Type 1 UV-Diazo 350 – 460 nm
UV-Integrator 126, Type 2 UV-A 315 – 410 nm
UV-Integrator 126, Type 3 UV 250 – 410 nm (STD)
UV-Integrator 126, Type 4 UV-B 280 – 315 nm
UV-Integrator 126, Type 5 UV-C

By addition of the incidence of the light quantities during the exposure cycle, relative values are calculated. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

TECHNICAL DATA
Spectral range: UV 250 – 410 nm
Measuring range: 0 to 5,000 mW/cm2
Display: 6-digit LCD
Display range: 0 to 999,999 mJ/cm2
Power source: long life 3.6 V Lithium Battery
Power consumption: 100 µA
Battery service life: 10,000 hrs
Dimensions: 4.5” x 2.4” x 0.5” (115 x 60 13 mm)
Weight: approx. 8.8 ounce (250 g)
Temperature range: 0 to 45° Centigrade
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-Integrator 126 can withstand max. 110° Centigrade for up to 10 seconds. The temperature of the housing should not exceed 45° Centigrade.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-224 UV-INT 126 T1 UV-DIAZO

M007-225 UV-INT 126 T2 UV-A

M007-226 UV-INT 126 T3 UV

M007-227 UV-INT 126 T4 UV-B

M007-228UV-INT 126 T5 UV-C


NEW ADDITION UV-INTEGRATOR 07

The UV-Integrator 07 is a high quality UV measuring instrument. It is used to measure UV energy of different light sources, especially on printing machines. It is ideal to ensure quality control of printing and drying processes.

With its diameter of only 2.75” (70 mm) is it one of the smallest pass-through Integrators available. Due to the round shape it bears a very small risk to get stuck somewhere inside. It is reliable and simple to use. The UV-Integrator 07 is available in five different measuring ranges. By addition of the incidence of the light quantities during the exposure cycle, relative values are calculated. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

The UV-Integrator 07 is available in five different measuring ranges:

UV-Integrator 07, Type 1 UV-V (Diazo) 350 – 460 nm
UV-Integrator 07, Type 2 UV-A 315 – 400 nm
UV-Integrator 07, Type 3 UV 250 – 410 nm
UV-Integrator 07, Type 4 UV-B 280 – 315 nm
UV-Integrator 07, Type 5 UV-C 230 – 280 nm

TECHNICAL DATA
Spectral range: UV 250 – 410 nm
Measuring range: 0 to 5,000 mW/cm2
Display: 6-digit LCD
Display range: 0 to 999,999 mJ/cm2
Power source: long life 3.6 V Lithium Battery
Power consumption: 100 µA
Battery service life: 10,000 hrs
Dimensions: Æ 2.75” (70 mm), height ½” (13 mm)
Weight: approx. 4 ounce (120 grs.)
Temperature range: 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-Integrator 07 can withstand max. 110° C / 230° F for up to 10 seconds. The temperature of the housing should not exceed 45° C / 112° F.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-209 RADIOMETER INTEGRATOR 07 T1

M007-210 RADIOMETER INTEGRATOR 07 T2

M007-212 UV-INTEGRATOR 07 T4

M007-213 RADIOMETER INTEGRATOR 07 T5



M007-209 UV Integrator 07 Radiometer Datasheet


NEW ADDITION RADIOMETER CABLED DETECTOR BLACK SERIES


+ UV intensity mW/cm²
+ 1 channel

The UV-Meter Black Standard MINI is a high quality, low cost UV measuring instrument. All measurements are expressed in mW/cm2 in order to compare light sources or to check uniformity of the light emission. Typical application fields are the control of units for the exposure of diazo, polymer, chromaline and daylight films in the graphic arts industry, suntan equipment, sterilisation units and other fields of photo bioIogy. The display readings are fictitiously. The basic setting is done by means of a potentiometer.

TECHNICAL DATA
Max. Power input : sensor input 1000W/cm²
Wavelength: 315 – 410 nm UV-A (or other)
Temperature: 0 - 45 C
Display: 4 Digits
Range X 1 : 0 - 19,99 mW/cm²
Weight: approx. 200 grams
Battery: 9 Volt Battery
Dimensions: 105 mm x 60 mm x 24 mm
Sensor cable: 1 meter
Sensor Æ 40 mm x 10 mm
Base Accuracy: ± 5 %

While on the conveyer belt, the UV sensor of the UV-Meter can withstand max. 110° C / 230° F for up to 10 seconds. The temperature of the housing should not exceed 45° C / 113° F.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery.


M007-193 RADIOMETER UV-V MINI DIAZO

M007-194 RADIOMETER MINI UV-A BLK STD

M007-195 RADIOMETER MINI UV-B MTR BLK

M007-196 RADIOMETER MINI UV-C MTR BLK

M007-197 RADIOMETER MINI UV- MTR BLK

M007-198 RADIOMETER UV-V SPARE BLACK

M007-199 RADIOMETER UV-A MINI BLK SPR

M007-201 RADIOMETER UV-B SPR BLK MINI

M007-202 RADIOMETER UV-C SPR BLK MINI

M007-203 RADIOMETER UV- SPR BLK MINI



M007-193 UV Meter Black Standard Series Mini Datasheet




NEW ADDITION UV-METER BLACK STANDARD SERIES

+ UV intensity mW/cm²
+ 2 channel x1/x10
+ Probe type sensor

All measurements are expressed in mW/cm2 in order to compare light sources or to check uniformity of the light emission. Typical application fields are the control of units for the exposure of diazo, polymer, chromaline and daylight films in the graphic arts industry, suntan equipment, sterilization units and other fields of photo bioIogy. The display readings are fictitiously. The basic setting is done by means of a potentiometer.

TECHNICAL DATA
Max. Power input : sensor input 1000W/cm²
Wavelength: 315 – 410 nm UV-A (or other)
Temperature: 0 - 45 C
Display: 4 Digits
Range X 1 : 0 - 19,99 mW/cm²
Range X 10 : 0 - 19 9,9 mW/cm²
Weight: approx. 200 grams
Battery: 9 Volt Battery
Dimensions: 140 mm x 75 mm x 24 mm
Sensor cable: 1 meter
Sensor Æ 40 mm x 10 mm
Base Accuracy: ± 5 %

The probe-type sensor of the UV-Meter can withstand max. 110° C / 230° F for up to 10 seconds. The temperature of the housing should not exceed 45° C / 113° F.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration.

M007-186 RADIOMETER BLACK STD METER T1

M007-187 RADIOMETER BLACK STD METER T2

M007-188 RADIOMETER BLACK STD METER T3

M007-189 RADIOMETER BLACK STD METER T4

M007-190 RADIOMETER BLACK STD METER T5



UV-INTEGRATOR 140 W SPECIAL

The UV-INTEGRATOR 140 W SPECIAL is a high quality UV measuring instrument. It is used to measure UV energy of different light sources, especially on printing machines. It was specially designed with a recess in the housing for better handling. It is ideal to ensure quality control of printing and drying processes.

The UV-Integrator 140 is available in six different measuring ranges:
Item 9.1 UV-Integrator 140, Type 1, Diazo 350 – 460 nm
Item 9.2 UV-Integrator 140, Type 2, UV-A 315 – 400 nm
Item 9.3 UV-Integrator 140, Type 3, UV 250 – 410 nm
Item 9.4 UV-Integrator 140, Type 4, UV-B 280 – 315 nm
Item 9.5 UV-Integrator 140, Type 5, UV-C 230 – 280 nm
Item 9.6 UV-Integrator 140, Type 6, UV-V 395 – 445 nm

Big size, heavy duty pass-through Integrator with a diameter of 140 mm. It is reliable and simple to use.

TECHNICAL DATA
Spectral range: UV 250 – 410 nm
Measuring range: 0 to 5,000 mW/cm2
Display: 6-digit LCD
Display range: 0 to 999,999 mJ/cm2
Power source: long life 3.6 V Lithium Battery
Power consumption: 100 µA
Battery service life: 10,000 hrs
Dimensions: Æ 5.5” (140 mm)
Height ½” (13 mm)
Weight: approx. 16 ounce (450 grs.)
Temperature range: 0 to 45° Celsius
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-Integrator 140 can withstand max. 110° C / 230° F for up to 10 seconds. The temperature of the housing should not exceed 45° C / 113° F.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Recalibration will also be necessary after change of battery.

M007-219 UV-INT 140 T1 UV-DIAZO

M007-220 UV-INT 140 T2 UV-A

M007-221 UV-INT 140 T3 UV

M007-222 UV-INT 140 T4 UV-B

M007-223 UV-INT 140 T5 UV-C

M007-219 Recessed Handle UV Integrator 140W Special Radiometer Datasheet


UV POWER MONITORING

UV POWER MONITORING
FOR UV-SOURCES AND SYSTEMS, 1 CHANNEL

UV-RANGES 230 - 410 nm, (standard), or UV-A, UV-B, UV-C (254nm)

OUTPUT SIGNAL 0-10V, photo diode directly mounted to lamp housing, temperature resistant up 70 degrees, 2 meter sensor cable, or quartz fibre cable, temperature resistant up to 350 degrees,
Or water-proof sensor housing with UV-C sensor for purification systems display in front plate or separate housing.

M007-230 UV-POWER MONITOR 70 FP UP TO 70c

M007-231 UV-POWER MONITOR 350 QUARTZ FIBR

M007-232 UV-POWER MONITOR 350H QUARTZ FIBR

M007-233 UV-POWER MONITOR 10 WP PHOTO DIO

M007-234 UV-POWER MONITOR 10H PHOTO DIO

M007-235 OUTPUT SIGNAL ALERT OP

M007-230 UV Multiple Channel Power Monitoring Radiometer Datasheet


MICROPROCESSOR POWER MONITORING DOSIMETER »



Constant MICROPROCESSOR POWER MONITORING for UV-Sources and systems, 1-8 channels UV, UV-A, UV-B and UV-C Sensors
UV-Monitoring and Level Alarm

TYPES
Photo Monitoring - Photo Diode, up to 70 degrees C, display in front plate
1 measuring point
1 measuring point, with comport

Photo Monitoring - Photo Diode, up to 70 degrees C, display in seperate housing
1 measuring point
1 measuring point, with comport

Photo Monitoring - Quartz Fiber Cable, up to 350 degrees C, display in front plate
1 measuring point
1 measuring point, with comport

Photo Monitoring - Quartz Fiber Cable, up to 350 degrees C, display in seperate housing
1 measuring point
1 measuring point, with comport

RADIOMETRIC
Dynamic Range: 0 to 1500 mW/cm2
Display: 0-100% or 0-1500 mW/cm2
Out of Band Rejection: VIS and IR

SENSORS
UV- 250nm - 410nm
UV-C 230nm - 280nm
UV-B 280nm - 315nm
UV-A 315nm - 410nm

ELECTRICAL/MECHANICAL
Line Power: 90-230 V AC
Size: 200mm x 250mm x 60mm
Weight: 520 grams
Temp. Range: 0 - +30 C
Display: LCD 2x20 lines
Option: 0 - 10 volt output

M007-236 UV-MPM8 70 FP 1 MEASURING POINT

M007-237 UV-MPM8 70FP 1 MEASURING POINT

M007-238 UV-MPM8 70H 1 MEASURING POINT

M007-239 UV-MPM8 70H 1MEASURING COMPORT

M007-240 UV-MPM8 350FP W/COMPORT

M007-241 UV-MPM8 350FP 1 MEASURING POINT

M007-242 UV-MPM8 350H, 1 MEASURING POINT

M007-243 UV-MPM8 350H, 1 MEASURING POINT



M007-236 UV Microprocessor Power Monitoring Datasheet


AUTOMATIC UV-POWER CONTROL »

The AUTOMATIC UV-POWER CONTROL Dosimeter provides:
Constant UV-Monitoring
Automatic UV-Power Regulation
In case of deviation from threshold values
For UV Sources and Systems, 1-8 lamps
UV, UV-A, UV-B and UV-C sensors

TYPES
Automatic UV-Power Regulation - Photo Diode, up to 70 degrees C, display in front plate, 1 measuring point
Automatic UV-Power Regulation - Photo Diode, up to 70 degrees C, display in seperate housing, 1 measuring point
Automatic UV-Power Regulation - Quartz Fiber Cable, up to 350 degrees C, display in front plate, 1 measuring point
Automatic UV-Power Regulation - Quartz Fiber Cable, up to 350 degrees C, display in seperate housing, 1 measuring point

RADIOMETRIC
Dynamic Range: 0 to 1500 mW/cm2
Display: 0-100% or 0-1500 mW/cm2
Out of Band Rejection: VIS and IR

SENSORS
UV- 250nm - 410nm
UV-C 230nm - 280nm
UV-B 280nm - 315nm
UV-A 315nm - 410nm

ELECTRICAL/MECHANICAL
Line Power: 90-230 V AC
Size: 200mm x 250mm x 60mm
Weight: 520 grams
Temp. Range: 0 - +30 C
Display: LCD 2x20 lines
Option: 0 - 10 volt output

M007-244 AUTO UV POWER REGULATION 70
M007-245 AUTO UV POWER REGULATION 70H
M007-246 AUTO UV REGULATION 350FP
M007-247 AUTO UV POWER REGULATION 350C

M007-244 UV AUTOMATIC UV POWER REGULATION Datasheet


UV-MONITORING DATALOG 12 CHANNEL »



The UV-MONITORING DATALOG 12 CHANNEL is a new portable UV-Data sampler for UV Curing sytems, max 12 channels.

UV + Temperature sensors profile analyzing and 3D-UV Data acquisition

RADIOMETRIC
Dose Range: 0 to 100,000 mJ/cm2
Dynamic Range: 0 to 1500 mW/cm2
Sample Rate: 1.0 sec to 1h
Out of Band Rejection: VIS and IR

SENSORS
UV- 250nm - 410nm
UV-C 230nm - 280nm
UV-B 280nm - 315nm
UV-A 315nm - 410nm

TEMPERATURE SENSOR
Range: -0 to +100 C

ELECTRICAL/MECHANICAL
Size: 200mm x 250mm x 60mm
Weight: 520 grams

Display: PC-System, USB / RS232
Software: Windows 98,2000,XP - including comfortable datalogger software, exportable files to EXCEL
The data sampler is running in stand along and online mode.

M007-248 UV-MONITORING DATALOG

M007-249 UV-MONITORING WIRELESS

M007-250 UV SENSOR 250-410

M007-251 SENSOR UV-A 315-410NM

M007-252 SENSOR UV-B 280-315NM

M007-253 SENSOR UV-C 230-280NM

M007-254 SENSOR TEMP 0-110

M007-255 SENSOR UV WIRELESS

M007-256 SENSOR UV-A WIRELESS

M007-257 SENSOR UV-B WIRELESS

M007-258 SENSOR UV-C WIRELESS

M007-259 SENSOR TEMP WIRELESS

M007-248 UV Monitoring Datalog UV Data Sampler Datasheet


UV-INTENSITY METER SMA CONNECTION


The UV-INTENSITY METER SMA features:

+ UV-intensity mW/cm2
+ Compact size
+ Portable
+ Standard SMA socket
+ 2 m flexible light guide

The UV-intensity meter SMA is a high quality electro-optic UV measuring instrument. It is selfcontained, battery-operated, portable, light-weight and easy to handle. It is specially designed to measure and display peak UV intensity in hard accessible curing chambers such as e.g. narrow web presses in order to evaluate system performance. The measurement head which contains the optics is attached to the upper end of the torch-like instrument. To take a measuring the flexible light guide is connected to an SMA socket which is fixed installed in the lamp housing. The UV-intensity meter SMA is available in two different UV-bands. In the basic version it is equipped with one UV sensor for the measuring of:

Full UV spectral area 230 – 410 nm

With the increasing employment of narrow web presses and flexo print technology, it has become necessary to establish a method of measuring system performance. Degradation of UV lamps, light guides, and reflectors can cause decreases in irradiance and create curing problems. The UV-intensity meter SMA is the right answer and an effective method of quantifying UV output. It provides the operator with instant feedback as to the performance of his UV curing system. A 9 V battery block ensures extremely long life in excess of 100,000 readings. After the flexible light guide has been connected to the SMA socket at the lamp the measurement can then be viewed directly on the LCD display.
It can monitor UV intensities up to 9,990 mW/cm2

TECHNICAL DATA
Spectral range: UV 230 – 410 nm (Standard)
Max. Power Input 0 to 9,990 mW/cm2
Display: LCD, 3 digits X 10
Display range: 0 to 9,990
Measuring range: 0 to 9,990 mW/cm2
Power source: 9 V Block Battery
Power consumption: 20 µA
Battery service life: 2,000 hrs (100.000 Measurings)
Dimensions: 6.25” (158 mm) x 1.6” (40 mm) x 1.3” (34 mm)
Weight: approx. 4 ounce (100 g)
Length of light guide: approx. 2 m
Operating temperature: 32 to 122° F / 0 to 50° C
Base Accuracy: ± 5 %
The maximum permissible temperature at the tip of the light guide is 350° C/ 660° F.
The temperature of the housing should not exceed 122° F / 50° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

Calibration:
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration with certificate

M007-274 Radiometer UV Meter SMA UVA

M007-275 Radiometer UV Meter SMA UVA


UV-DATA SAMPLE 1-8 CHANNEL PL2508 SPECIAL »

The UV-DATA SAMPLER 1-8 CHANNEL PL 2508

+ Up to 8 channels
+ Individual UV & temperature measuring
+ temperature measuring 0 – 150°C (32 – 302°F)
+ Up to 8 probe-type sensors (UV and temp)
+ UV intensity mW/cm2
+ UV dose mJ/cm2
+ Pass-through data acquisition
+ Parameter selection
+ Auto scale function
+ Free selectable Integral
+ Graphic charts on PC via ComPort
+ Result storing on PC via ComPort
+ Microsoft Evaluation Software
+ Auto off

The UV-Data Sampler 1-8 Channel is a portable, pass-through, UV & temperature data sampling unit for UV & IR Curing systems, UV & IR Profile Analysing and 3D-UV & IR Data Acquisition. According to the customers’ requirements, the UV-Data Sampler 1-8 Channel is available in various configurations: Any combination of up to 8 individual sensors can be configured:

UV 230 – 410 nm
UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
0 - 302° F / 0 to 150° C

The UV-Data Sampler 1-8 Channel profiling ultraviolet and temperature data sampling system has been specifically designed to measure UV-radiation and temperature on high-end UV-IR curing machines. Via ComPort, it is connected to a PC in order to pre-select parameters for the measuring cycle. After passage of the curing chamber the recorded data can be downloaded to a computer for further editing by Microsoft Evaluation Software. The measurement, integrating, and recording of data from all sensor channels takes place at user-defined intervals. The sensors are probe-type round sensors connected with a flexible cable. The measuring results are displayed on graphs as mW/cm², mJ/cm² and as a temperature curve. The monitor displayed graphs show the complete profile and offers zooming and auto scale functions. Peaks and Integrals are free selectable on screen and will also be displayed as digital numbers. The powerful Windows CE evaluation software is included and enables the user to synchronise the UVData Sampler 1-8 Channel with a PC via RS232.

TECHNICAL DATA
Available UV spectral ranges:
UV 250 – 410 nm
UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
Available temperature range: 32 to 302° F / 0 to 150° C
Measuring range: 0 to 5,000 mW/cm2
Dose range: 0 to 100,000 mJ/cm2
Dynamic range: 0 to 1,000 mW/cm2
Amplification: x1, x10, x100, +adjustable
Sample rate: 0.01 sec to 1 h
Recording time: 90 sec to 300 days
Power source: 8 x 1.5 V rechargeable battery
Power consumption: 20 µA
Battery service life: 2,000 hrs
Dimensions: base unit : approx. 9” x 6” x 2” (220 x 150 x 50 mm) sensors : round approx. 1.5” x .35” (40 x 10 mm)
Weight: approx. 53 ounce (1500 g)
Temperature range: 32 to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-Data Sampler 1-8 Channel can withstand max. 110° C/230° F for up to 10 seconds. The temperature of the housing should not exceed 45° C/113° F.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after replacement of batteries. PTB traceable calibration.

M007-572 RADIOMETER UV-DATA SAMPLER 1

M007-573 UV-DATA SAMPLER 2

M007-574 RADIOMETER UV-DATA SAMPLER 3

M007-575 RADIOMETER UV-DATA SAMPLER 4

M007-576 RADIOMETER UV-SAMPLER 5

M007-577 RADIOMETER UV-SAMPLER 6

M007-578 RADIOMETER UV-SAMPLER 7

M007-579 RADIOMETER UV-SAMPLER 8

M007-580 RADIOMETER SENSOR UV

M007-581 RADIOMETER SENSOR UV-A

M007-582 RADIOMETER SENSOR UV-B

M007-583 RADIOMETER SENSOR UV-C

M007-584 RADIOMETER SENSOR UV-C

M007-585 RADIOMETER SENSOR UV-C

M007-586 RADIOMETER SENSOR UV-C

M007-587 RADIOMETER SENSOR TEMP 0-150

M007-588 RADIOMETER SENSOR NITROGEN

M007-589 RADIOMETER BAT CGR RLG 7008

M007-752 PL2508 UV Data Sampler Radiometer - 1 to 8 Channel Datasheet


UV-INTEGRATOR DVD FOR CD »


The UV-INTEGRATOR DVD FOR CD is a self-contained, high quality UV measuring instrument.

+ UV-intensity mW/cm2
+ UV-dose mJ/cm2
+ Temperature measuring °C/°F
+ Special design Æ 4.7“ / 120 mm with center hole

It is specially designed to measure, record and display peak UV intensity, UV dosage and temperature in the UV curing process of CD and DVD production. In the standard version it is equipped with one UV sensor and one temperature sensor for the measuring of:
Full UV 230 – 410 nm
Temp 32° to 230° F / 0° to 110° C

With this total UV band measuring, extra temperature measuring and its special size and design it is particularly suitable to cover the measuring requirements of UV curing applications in CD and DVD production. Due to its UV sensor and the integrated microprocessor the UV-T Integrator DVD can measure, record and display the peak UV-intensity of the total UV spectrum (mW/cm2).

Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated as the total Integral of UVdosage over the full UV spectral bands. An extra sensor measures temperatures from 32° to 230° F / 0° to 110° C The two sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle all measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. As an option, this microprocessor integrator is additionally equipped with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2) and (°C/°F)

TECHNICAL DATA
Spectral range: UV 230 – 410 nm (Standard)
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 230° F / 0 to 110° C
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 hrs
Dimensions: Æ 4.7” (120 mm), height 1/4” (6,5 mm)
Weight: approx. 10,5 ounce (290 g)
Operating temperature: 32 to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-T Integrator DVD can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration with certificate.

M007-276 RADIOMETER UV-V DIAZO DVD T1

M007-277 RADIOMETER UV-A DVD T2

M007-278 RADIOMETER UV INT DVD T3

M007-279 RADIOMETER UV-B DVD T4

M007-280 RADIOMETER UV-C DVD T5

M007-281 RADIOMETER UV-3C INT DVD

M007-282 RADIOMETER UV+T DVD UV-VDIA

M007-283 RADIOMETER UV+T DVD UV-A

M007-284 RADIOMETER UV+T DVD UV

M007-285 RADIOMETER UV+T DVD UV-B T4

M007-286 RADIOMETER UV+T DVD UV-C T5

M007-287 RADIOMETER UV-3C-T INT DVD

M007-288 RADIOMETER UV-2C DVD DIAZO

M007-289 RADIOMETER UV-2C DVD UVA+UVB

M007-290 RADIOMETER UV-2C DVD UV+UV-A

M007-291 RADIOMETER UV-2C DVD UV+UV-B

M007-292 RADIOMETER UV-2C DVD UV+UV-V

M007-293 RADIOMETER UV-2C-T INT DVD

M007-294 RADIOMETER UV-2C-T INT DVD

M007-295 RADIOMETER UV-2C-T INT DVD

M007-296 RADIOMETER UV-2C-T INT DVD

M007-297 UV-2C-T INT DVD

M007-298 RADM UV-4C INT DVD

M007-276 UV-T Integrator Radiometer for DVD and CD Production Datasheet


UV-POWER INTEGRATOR 06 »

The UV-POWER INTEGRATOR 06 is a small, only 6 mm flat, self-contained, pass-through UV-Microprocessor Integrator

+ UV intensity mW/cm2
+ UV dose mJ/cm2
+ Selectable “triggered mode”*
+ Temperature (option UV-T)
+ 2 line LCD display
+ Extra flat only 6 mm / .25 inc

It is specially designed to measure, record and display peak UV intensity, UV dosage, and optionally (UV-T) temperature, in the UV curing process of narrow web presses and in some applications of the flexo print. It is equipped with one UV sensor and optionally with one additional temperature sensor for the individual measuring of:

UV 230 – 400 nm
Temp: 0 to 230° F / 0 to 110° C (option UV-T)

With this full band UV measuring and an extra temperature measuring, most of the measuring requirements of UV curing in extreme narrow applications can be covered. It measures only 4.5” x 2.5” x 0.25” (117 x 64 x 6 mm). Due to its integrated microprocessor the UV-Power Integrator 06 can measure, record and display the peak of the UV-intensity (mW/cm2). Additionally, it is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated as a total Integral of UV-dosage over the full UV spectral area 230 – 410 nm. This allows to determine a profile of how that energy is delivered at which intensity. Optionally, an extra sensor measures temperatures from 0 to 230° F / 0 to 110° C (option UV-T)

The sensor is on the back of the unit which also serves as a heat shield. After completion of the measuring cycle all measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. The measuring period is 30 seconds at a sampling rate of 200/sec.

TECHNICAL DATA
Spectral range: UV 230 – 410 nm
Temperature range: 0 to 230° F / 0 to 110° C (UV-T Power Integrator)
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Sampling rate: 0.005 sec (200/sec)
Display: LCD, 2 lines x 16 digits
Power source: 2 x long life 3.0 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: 4.5” x 2.5” x 0.25” (117 x 64 x 6 mm)
Weight: approx. 3 ounce (85 g)
Heat protection: Heat shield on back plate
Operating temperature: 32° to 113° F / 0 to 45° C
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-Power Integrator 06 can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-338 RADIOMETER UV PWR INT 06 T1

M007-339 RADIOMETER UV PWR INT 6 T2

M007-340 RADIOMETER UV PWR INTO 06 T3

M007-341 RADIOMETER UV-T PWR INT T1

M007-342 RADIOMETER UV-T PWR INT 6 T2

M007-343 RADIOMETER UV-T PWR INT 6 T3

M007-338 UV Power Integrator 06 Pass-through UV intensity and UV dose Radiometer Datasheet






UV-T INTEGRATOR 160 »

UV-T INTEGRATOR 160
+ UV intensity mW/cm2
+ UV dose mJ/cm2
+ Temperature °C/°F
+ Selectable “triggered mode”*
+ 2 line LCD display
+ Extra flat only 6 mm / .25 inch

It is specially designed to measure, record and display peak UV intensity, UV dosage and temperature, in the UV curing process of narrow web presses and in some applications of the flexo print. It is equipped with one UV sensor and optionally with one additional temperature sensor for the individual measuring of:

UV 230 – 400 nm
Temp: 0 to 230° F / 0 to 110° C

With this full band UV measuring and an extra temperature measuring, most of the measuring requirements of UV curing in extreme narrow applications can be covered. It measures only 4.5” x 2.5” x 0.25” (117 x 64 x 6 mm) Due to its integrated microprocessor the UV-T Power Integrator 06 can measure, record and display the peak of the UV-intensity (mW/cm2).Additionally, it is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated as a total Integral of UV-dosage over the full UV spectral area 230 – 410 nm. This allows to determine a profile of how that energy is delivered at which intensity. An extra sensor measures temperatures from 0 to 230° F / 0 to 110° C. The sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle all measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. The measuring period is 30 seconds at a sampling rate of 200/sec.

The following versions are available:
UV-T Power Integrator 06, Type 1 Diazo 350 – 460 nm
UV-T Power Integrator 06, Type 2 UV-A 315 – 400 nm
UV-T Power Integrator 06, Type 3 UV 230 – 400 nm
UV-T Power Integrator 06, Type 6 UV-V 395 – 445 nm

TECHNICAL DATA
Spectral range: UV 230 – 410 nm
Temperature range: 0 to 230° F / 0 to 110° C
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Sampling rate: 0.005 sec (200/sec)
Display: LCD, 2 lines x 16 digits
Power source: 2 x long life 3.0 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: 4.5” x 2.5” x 0.25” (117 x 64 x 6 mm)
Weight: approx. 3 ounce (85 g)
Heat protection: Heat shield on back plate
Operating temperature: 32° to 113° F / 0 to 45° C
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-T Power Integrator 06 can withstand max. 230° F / 110° C for up to 10
seconds. The temperature of the housing should not exceed 113° F / 45° C.
Because of uneven radiation distribution of the UV light source and different type of construction of the
measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate
.

M007-344 RADIOMETER M UV-T INT 160 T1

M007-345 RADIOMETER UV-T INT 160 T2

M007-346 RADIOMETER UV-T INT 160 T3

M007-347 RADIOMETER UV-T INT 160 T4

M007-348 RADIOMETER UV-T INT 160 T5

M007-344 UV-T Integrator 160 Radiometer for narrow web presses and flexo print Datasheet




UV-CUBE INTEGRATOR »

The UV-CUBE INTEGRATOR is a self-contained, high quality UV measuring instrument.

+ 3D measuring
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Various UV-ranges available
+ Permanent or „triggered“ measuring mode*
+ USB ComPort (option)
+ Graphic chart on computer (option)

It is designed to measure and display peak UV intensity and UV dosage in the UV curing process. In the standard version it is equipped with one UV sensor for the measuring of:

Full UV 230 – 410 nm

With this total UV band peak intensity and dose measuring, most of the measuring requirements of UV curing applications can be covered. Due to its UV sensor and the integrated microprocessor the UV-Cube Integrator can measure and display the peak UV-intensity of the total UV spectrum (mW/cm2). Additionally, this UV-Cube Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated as the total Integral of UV-dosage over the full UV spectral bands. Optionally it is available with an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C.

The sensor is on one side of the unit, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. The UV-Cube Integrator is optionally available equipped with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2)

TECHNICAL DATA
Spectral range: UV 230 – 410 nm (Standard)
Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to 113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-Cube Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-354 UV Cube Integrator Radiometer T1

M007-355 UV Cube Integrator Radiometer T2

M007-356 UV Cube Integrator Radiometer T3

M007-354 UV Cube Integrator Radiometer T4

M007-354 UV Cube Integrator Radiometer T5



M007-354 UV Cube Integrator Datasheet




UV-3C CUBE MICROPROCESSR INTEGRATOR »

The UV-3C CUBE MICROPROCESSR INTEGRATOR features:

+ 3D Measuring
+ UV-A + UV-B + UV-C (UV-V)
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Temperature measuring °C/°F (option)
+ Various UV-ranges available
+ Permanent or "triggered“ measuring mode*
+ SD-Card Slot (option)
+ Graphic and numerical chart on computer (option)

The UV-3C Cube Integrator is a self-contained, high quality UV measuring instrument. It is designed to measure and display peak UV intensity and UV dosage in the UV curing process. It is equipped with three different UV sensors for the individual measuring of

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm*
UV 230 – 410 nm

With these three different UV-bands plus the total UV band, most of the measuring requirements of UV curing applications can be covered. Due to its three different UV sensors and the integrated microprocessor the UV-3C-T can measure, record and display the peak of the UV-energy (mW/cm2) for each UV-band individually plus the peak of total UV energy.

Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B and UV-C or UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. Optionally, an extra sensor measures temperatures from 32 to 230° F / 0 to 110° C

*This Microprocessor Integrator features a selectable "triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The sensors are on one side of the unit in different directions, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display.
A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. The UV-3C Cube Integrator is optionally available equipped with an SD-Card Slot and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2)

The UV-3C Cube Integrator is available as follows:
UV-3C Cube Integrator UV-A, UV-B, UV-C
UV-3C Cube Integrator UV-A, UV-B, UV-V

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm*
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 1,000 charging cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to 113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-3C Cube Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuri\ng devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-359 UV-3C Cube Microprocessor Integrator

M007-359 UV-3C Cube Microprocessor Integrator Datasheet


UV PLUS TEMPERATURE CUBE MICROPROCESSOR INTEGRATOR »

The UV PLUS TEMPERATURE CUBE MICROPROCESSOR INTEGRATOR features:

+ 3D measuring
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Temperature measuring °C/°F
+ Various UV-ranges available
+ Permanent or „triggered“ measuring mode*
+ SD-Card Slot (option)
+ Graphic and numerical chart on computer (option)


The UV-T Cube Integrator is a self-contained, high quality UV measuring instrument. It is designed to measure and display peak UV intensity and UV dosage in the UV curing process.

It is equipped with one UV sensor and one temperature for the measuring of:

Full UV 230 – 410 nm
Temp. 0 – 115 °C / 32 – 232 °F

With this total UV band peak intensity and dose measuring, most of the measuring requirements of UV curing applications can be covered.
Due to its UV sensor and the integrated microprocessor the UVT -Cube Integrator can measure and display the peak UV-intensity of the total UV spectrum (mW/cm2).

Additionally, this UV-T Cube Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated as the total Integral of UV-dosage over the full UV spectral bands.
Equipped with an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C.

*This Integrator features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The sensor is on one side of the unit, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display.
A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

The UV-T Cube Integrator is optionally available equipped with an SD-Card Slot and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2)

The UV-T Cube Integrator is available in six different measuring ranges:

Item 52.3.1 UV-T Cube Integrator, Type 1 Diazo 350 – 460 nm
Item 52.3.2 UV-T Cube Integrator, Type 2 UV-A 315 – 400 nm
Item 52.3.3 UV-T Cube Integrator, Type 3 UV 230 – 410 nm (Standard)
Item 52.3.4 UV-T Cube Integrator, Type 4 UV-B 280 – 315 nm
Item 52.3.5 UV-T Cube Integrator, Type 5 UV-C 230 – 280 nm
Item 52.3.6 UV-T Cube Integrator, Type 6 UV-V 395 – 445 nm

TECHNICAL DATA
Spectral range: UV 230 – 410 nm (Standard)
Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Measuring range: 0 to 115°C / 32 to 232°F
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 1,000 charging cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to 113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-T Cube Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-360 UV Plus Temperature Cube Microprocessor Integrator T1

M007-361 UV Plus Temperature Cube Microprocessor Integrator T2

M007-362 UV Plus Temperature Cube Microprocessor Integrator T3

M007-363 UV Plus Temperature Cube Microprocessor Integrator T4

M007-364 UV Plus Temperature Cube Microprocessor Integrator T5

M007-360 UV Plus Temperature Cube Microprocessor Integrator Radiometer Datasheet


UV-3C-T TEMPERATURE CUBE MICROPROCESSOR »

The UV-3C-T TEMPERATURE CUBE MICROPROCESSOR features:

+ 3D measuring
+ UV-A + UV-B + UV-C (UV-V*)
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Temperature measuring °C/°F
+ Various UV-ranges available
+ Permanent or „triggered“ measuring mode*
+ SD-Card Slot (option)
+ Graphic and numerical chart on computer (option)

The UV-3C-T Cube Integrator is a self-contained, high quality UV measuring instrument. It is designed to measure and display peak UV intensity and UV dosage in the UV curing process.
It is equipped with three different UV sensors and one temperature sensor for the individual measuring of

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm*
UV 230 – 410 nm
Temp 32 to 230° F / 0 to 110° C

With these three different UV-bands plus the total UV band and an extra temperature measuring, most of the measuring requirements of UV curing applications can be covered. Due to its three different UV sensors and the integrated microprocessor the UV-3C-T can measure, record and display the peak of the UV-energy (mW/cm2) for each UV-band individually plus the peak of total UV energy.

Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B and UV-C or UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band.

An extra sensor measures temperatures from 32 to 230° F / 0 to 110° C
*This Microprocessor Integrator features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The sensors are on one side of the unit in different directions, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

The UV-3C-T Cube Integrator is optionally available equipped with an SD-Card Slot and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2)

The UV-3C-T Cube Integrator is available as follows:
UV-3C-T Cube Integrator UV-A, UV-B, UV-C
UV-3C-T Cube Integrator UV-A, UV-B, UV-V*

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm*
UV 230 – 410 nm

Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Measuring range: 0 to 115°C / 32 to 232°F
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 1,000 charging cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to 113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-3C-T Cube Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-365 UV-3C-T Temperature Cube Microprocessor Radiometer

M007-365 UV-3C-T Temperature Cube Microprocessor Radiometer


UV-2C CUBE MICROPROCESSOR »

The UV-2C CUBE MICROPROCESSOR features:

+ 3D measuring
+ Selection of two different 2 sensors
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Temperature measuring °C/°F (option)
+ Various UV-ranges available
+ Permanent or „triggered“ measuring mode*
+ SD-Card Slot (option)
+ Graphic and numerical chart on computer (option)

The UV-2C Cube Integrator is a self-contained, high quality UV measuring instrument. It is designed to measure and display peak UV intensity and UV dosage in the UV curing process.It is equipped with a selection of two different UV sensors.

With these two different UV-bands plus the total UV band, most of the measuring requirements of UV curing applications can be covered. Due to its two UV sensors and the integrated microprocessor the UV-3C-T can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV intensity. Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (e.g. UV-A, UV-B, UV-C or UV-V) individually and as total Integral of UV-dosage. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. Optionally, an extra sensor measures temperatures from 32 to 230° F / 0 to 110° C

*This Microprocessor Integrator features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The sensors are on one side of the unit in different directions, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

The UV-2C Cube Integrator is optionally available equipped with an SD-Card Slot and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2)

The UV-2C Cube Integrator is available as follows:
UV-2C Cube Microprocessor Integrator UV-A + UV-V
UV-2C Cube Microprocessor Integrator UV-A + UV-B
UV-2C Cube Microprocessor Integrator UV + UV-A
UV-2C Cube Microprocessor Integrator UV + UV-B
UV-2C Cube Microprocessor Integrator UV + UV-V
UV-2C Cube Microprocessor Integrator UV-B + UV-V
UV-2C Cube Microprocessor Integrator UV-C + UV-V

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 1,000 charging cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to 113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-2C Cube Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.

Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-366 UV-2C Cube Microprocessor Radiometer Integrator T1

M007-367 UV-2C Cube Microprocessor Radiometer Integrator T2

M007-368 UV-2C Cube Microprocessor Radiometer Integrator T3

M007-369 UV-2C Cube Microprocessor Radiometer Integrator T4

M007-370 UV-2C Cube Microprocessor Radiometer Integrator T5

M007-366 UV-2C Cube Microprocessor Radiometer Integrator Datasheet


UV-2C-T CUBE MICROPROCESSOR »

The UV-2C-T CUBE MICROPROCESSOR featuers:

+ 3D measuring
+ Selection of two different 2 sensors
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Temperature measuring °C/°F
+ Various UV-ranges available
+ Permanent or „triggered“ measuring mode*
+ SD-Card Slot (option)
+ Graphic and numerical chart on computer (option)

The UV-2C-T Cube Integrator is a self-contained, high quality UV measuring instrument. It is designed to measure and display peak UV intensity and UV dosage in the UV curing process. It is equipped with a selection of two different UV sensors and one temperature sensor.

With these two different UV-bands plus the total UV band, most of the measuring requirements of UV curing applications can be covered. Due to its two UV sensors and the integrated microprocessor the UV-3C-T can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV intensity. Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (e.g. UV-A, UV-B, UV-C or UV-V) individually and as total Integral of UV-dosage. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. An extra sensor measures temperatures from 32 to 230° F / 0 to 110° C
*This Microprocessor Integrator features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The sensors are on one side of the unit in different directions, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. The UV-2C-T Cube Integrator is optionally available equipped with an SD-Card Slot and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2)


The UV-2C-T Cube Integrator is available as follows:
UV-2C-T Cube Microprocessor Integrator UV-A + UV-V + Temp
UV-2C-T Cube Microprocessor Integrator UV-A + UV-B + Temp
UV-2C-T Cube Microprocessor Integrator UV + UV-A + Temp
UV-2C-T Cube Microprocessor Integrator UV + UV-B + Temp
UV-2C-T Cube Microprocessor Integrator UV + UV-V + Temp
UV-2C-T Cube Microprocessor Integrator UV-B + UV-V + Temp
UV-2C-T Cube Microprocessor Integrator UV-C + UV-V + Temp

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Measuring range: 0 to 115 °C / 32 to 232 °F
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 1,000 charging cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %
While on the conveyer belt, the UV-2C Cube Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.
Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-371 UV-2C-T CUBE MICROPROCESSOR RADIOMETER INTEGRATOR

M007-372 UV-2C-T CUBE MICROPROCESSOR RADIOMETER INTEGRATOR

M007-373 UV-2C-T CUBE MICROPROCESSOR RADIOMETER INTEGRATOR

M007-374 UV-2C-T CUBE MICROPROCESSOR RADIOMETER INTEGRATOR

M007-375 UV-2C-T CUBE MICROPROCESSOR RADIOMETER INTEGRATOR



M007-371 M007-371 UV-2C-T CUBE MICROPROCESSOR RADIOMETER INTEGRATOR Datasheet




UV-4C CUBE MICROPROCESSOR INTEGRATOR »

The UV-4C CUBE MICROPROCESSOR INTEGRATOR features:

+ 3D measuring
+ UV-A + UV-B + UV-C + UV-V
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Various UV-ranges available
+ Permanent or „triggered“ measuring mode*
+ SD-Card Slot (option)
+ Graphic and numerical chart on computer (option)

The UV-4C Cube Integrator is a self-contained, high quality UV measuring instrument. It is designed to measure and display peak UV intensity and UV dosage in the UV curing process. It is equipped with four different UV sensors for the individual measuring of
UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV 230 – 410 nm

With these four different UV-bands plus the total UV band, most of the measuring requirements of UV curing applications can be covered. Due to its four different UV sensors and the integrated microprocessor the UV-4C can measure, record and display the peak of the UV-energy (mW/cm2) for each UV-band individually plus the peak of total UV energy.

Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B and UV-C or UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band.
*This Microprocessor Integrator features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The sensors are on one side of the unit in different directions, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. The UV-4C Cube Integrator is optionally available equipped with an SD-Card Slot and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2)

The UV-4C Cube Integrator is available as follows:
UV-4C Cube Microprocessor Integrator UV-A, UV-B, UV-C, UV-V

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 1,000 charging cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to 113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-4C Cube Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.

Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-376 UV-4C CUBE MICROPROCESSOR INTEGRATOR RADIOMETER



M007-376 UV-4C CUBE MICROPROCESSOR INTEGRATOR RADIOMETER DATASHEET




UV-3C CUBE LOGGER »

The UV-3C CUBE LOGGER features:

+ 3D measuring
+ UV-A + UV-B + UV-C (UV-V*)
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Temperature measuring °C/°F (option)
+ Various UV-ranges available
+ Permanent or „triggered“ measuring mode*
+ SD-Card Slot
+ Graphic and numerical chart on computer

The UV-3C Cube Logger is a self-contained, high quality UV measuring instrument. It is designed to measure and display peak UV intensity and UV dosage in the UV curing process.It is equipped with three different UV sensors for the individual measuring of

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm*
UV - 230 – 410 nm

With these three different UV-bands plus the total UV band, most of the measuring requirements of UV curing applications can be covered. Due to its three different UV sensors and the integrated microprocessor the UV-3C-T can measure, record and display the peak of the UV-energy (mW/cm2) for each UV-band individually plus the peak of total UV energy.

Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B and UV-C or UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band.

Optionally, an extra sensor measures temperatures from 32 to 230° F / 0 to 110° C
*This Microprocessor Logger features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The sensors are on one side of the unit in different directions, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display.
A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. The UV-3C Cube Logger is equipped with an SD-Card Slot and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2)

The UV-3C Cube Logger is available as follows:
UV-3C Cube Logger UV-A, UV-B, UV-C
UV-3C Cube Logger UV-A, UV-B, UV-V

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm or UV-V 395 – 445 nm
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 1,000 charging cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to 113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-3C Cube Logger can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-382 UV-3C CUBE LOGGER Radiometer

M007-382 UV-3C CUBE LOGGER Radiometer Datasheet


UV PLUS TEMPERATURE CUBE LOGGER »

The UV PLUS TEMPERATURE CUBE LOGGER features:

+ 3D measuring
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Temperature measuring °C/°F
+ Various UV-ranges available
+ Permanent or „triggered“ measuring mode*
+ SD-Card Slot
+ Graphic and numerical chart on computer

The UV-T Cube Logger is a self-contained, high quality UV measuring instrument. It is designed to measure and display peak UV intensity and UV dosage in the UV curing process.

It is equipped with one UV sensor and one temperature for the measuring of:
Full UV 230 – 410 nm
Temp. 0 – 115 °C / 32 – 232 °F

With this total UV band peak intensity and dose measuring, most of the measuring requirements of UV curing applications can be covered. Due to its UV sensor and the integrated microprocessor the UV- T Cube Logger can measure and display the peak UV-intensity of the total UV spectrum (mW/cm2).

Additionally, this UV-T Cube Logger is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated as the total Integral of UV-dosage over the full UV spectral bands. Equipped with an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C.
*This Logger features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The sensor is on one side of the unit, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. The UV-T Cube Logger is optionally available equipped with an SD-Card Slot and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2) The UV-T Cube Logger is available in six different measuring ranges:

UV-T Cube Logger, Type 1 Diazo 350 – 460 nm
UV-T Cube Logger, Type 2 UV-A 315 – 400 nm
UV-T Cube Logger, Type 3 UV 230 – 410 nm (Standard)
UV-T Cube Logger, Type 4 UV-B 280 – 315 nm
UV-T Cube Logger, Type 5 UV-C 230 – 280 nm
UV-T Cube Logger, Type 6 UV-V 395 – 445 nm

TECHNICAL DATA
Spectral range: UV 230 – 410 nm (Standard)
Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Measuring range: 0 to 115°C / 32 to 232°F
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 1,000 charging cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to 113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-T Cube Logger can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.

Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-383 UV PLUS TEMPERATURE CUBE LOGGER RADIOMETER T1

M007-384 UV PLUS TEMPERATURE CUBE LOGGER RADIOMETER T2

M007-385 UV PLUS TEMPERATURE CUBE LOGGER RADIOMETER T3

M007-386 UV PLUS TEMPERATURE CUBE LOGGER RADIOMETER T4

M007-387 UV PLUS TEMPERATURE CUBE LOGGER RADIOMETER T5



M007-383 UV PLUS TEMPERATURE CUBE LOGGER Datasheet




UV-3C-TEMPERATURE CUBE LOGGER »

The UV-3C-TEMPERATURE CUBE LOGGER featuers:

+ 3D measuring
+ UV-A + UV-B + UV-C (UV-V*)
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Temperature measuring °C/°F
+ Various UV-ranges available
+ Permanent or „triggered“ measuring mode*
+ SD-Card Slot
+ Graphic and numerical chart on computer

The UV-3C-T Cube Logger is a self-contained, high quality UV measuring instrument. It is designed to measure and display peak UV intensity and UV dosage in the UV curing process. It is equipped with three different UV sensors and one temperature sensor for the individual measuring of

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm*
UV - 230 – 410 nm
Temp 32 to 230° F / 0 to 110° C

With these three different UV-bands plus the total UV band and an extra temperature measuring, most of the measuring requirements of UV curing applications can be covered. Due to its three different UV sensors and the integrated microprocessor the UV-3C-T can measure, record and display the peak of the UV-energy (mW/cm2) for each UV-band individually plus the peak of total UV energy. Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B and UV-C or UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. An extra sensor measures temperatures from 32 to 230° F / 0 to 110° C
*This Microprocessor Logger features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The sensors are on one side of the unit in different directions, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.
The UV-3C-T Cube Logger is optionally available equipped with an SD-Card Slot and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2)

The UV-3C-T Cube Logger is available as follows:
UV-3C-T Cube Logger UV-A, UV-B, UV-C
UV-3C-T Cube Logger UV-A, UV-B, UV-V

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm or UV-V 395 – 445 nm
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Measuring range: 0 to 115°C / 32 to 232°F
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 1,000 charging cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to 113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-3C-T Cube Logger can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.
Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-388 UV-3C-T TEMPERATURE CUBE LOGGER RADIOMETER



M007-388 UV-3C-T TEMPERATURE CUBE LOGGER RADIOMETER Datasheet


UV-2C CUBE LOGGER »

The UV-2C CUBE LOGGER features:

+ 3D measuring
+ Selection of two different 2 sensors
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Temperature measuring °C/°F (option)
+ Various UV-ranges available
+ Permanent or „triggered“ measuring mode*
+ SD-Card Slot (option)
+ Graphic and numerical chart on computer (option)

The UV-2C Cube Logger is a self-contained, high quality UV measuring instrument. It is designed to measure and display peak UV intensity and UV dosage in the UV curing process. It is equipped with a selection of two different UV sensors. With these two different UV-bands plus the total UV band, most of the measuring requirements of UV curing applications can be covered. Due to its two UV sensors and the integrated microprocessor the UV-2C Logger can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV intensity. Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (e.g. UV-A, UV-B, UV-C or UV-V) individually and as total Integral of UV-dosage. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. Optionally, an extra sensor measures temperatures from 32 to 230° F / 0 to 110° C

*This Logger features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The sensors are on one side of the unit in different directions, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. The UV-2C Cube Logger is optionally available equipped with an SD-Card Slot and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2)

The UV-2C Cube Logger is available as follows:

UV-2C Cube Logger UV-A + UV-V
UV-2C Cube Logger UV-A + UV-B
UV-2C Cube Logger UV + UV-A
UV-2C Cube Logger UV + UV-B
UV-2C Cube Logger UV + UV-V
UV-2C Cube Logger UV-B + UV-V
UV-2C Cube Logger UV-C + UV-V

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 1,000 charging cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to 113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-2C Cube Logger can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-389 UV-2C CUBE LOGGER RADIOMETER

M007-390 UV-2C CUBE LOGGER RADIOMETER

M007-391 UV-2C CUBE LOGGER RADIOMETER

M007-392 UV-2C CUBE LOGGER RADIOMETER

M007-393 UV-2C CUBE LOGGER RADIOMETER



M007-389 UV-2C CUBE LOGGER RADIOMETER DATASHEET




UV-2C-TEMPERATURE CUBE LOGGER »

The UV-2C-TEMPERATURE CUBE LOGGER features:

+ 3D measuring
+ Selection of two different 2 sensors
+ UV-Intensity mW/cm2
+ UV-Dose mJ/cm2
+ Temperature measuring °C/°F
+ Various UV-ranges available
+ Permanent or „triggered“ measuring mode*
+ SD-Card Slot
+ Graphic and numerical chart on computer

The UV-2C-T Cube Logger is a self-contained, high quality UV measuring instrument. It is designed to measure and display peak UV intensity and UV dosage in the UV curing process.
It is equipped with a selection of two different UV sensors and one temperature sensor. With these two different UV-bands plus the total UV band, most of the measuring requirements of UV curing applications can be covered.Due to its two UV sensors and the integrated microprocessor the UV-2C-T Logger can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV intensity. Additionally, this UV-Logger is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (e.g. UV-A, UV-B, UV-C or UV-V) individually and as total Integral of UV-dosage. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. An extra sensor measures temperatures from 32 to 230° F / 0 to 110° C

*This Logger features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².
The sensors are on one side of the unit in different directions, while the display is on the opposite side. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

The UV-2C-T Cube Logger is optionally available equipped with an SD-Card Slot and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2)

The UV-2C-T Cube Logger is available as follows:
UV-2C-T Cube Logger UV-A + UV-V + Temp
UV-2C-T Cube Logger UV-A + UV-B + Temp
UV-2C-T Cube Logger UV + UV-A + Temp
UV-2C-T Cube Logger UV + UV-B + Temp
UV-2C-T Cube Logger UV + UV-V + Temp
UV-2C-T Cube Logger UV-B + UV-V + Temp
UV-2C-T Cube Logger UV-C + UV-V + Temp

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV 230 – 410 nm

Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Measuring range: 0 to 115 °C / 32 to 232 °F
Sampling rate: 0.005 sec (200/sec)
Measuring period: 30 sec.
Readiness phase: 120 sec.
Power source: 7.2 V NiMH Accu-Pack, 70 mA, re-chargeable
Power consumption: 20 µA
Battery service life: 1,000 charging cycles
Dimensions: 2.4” x 2.4” x 2.4” (60 x 60 x 60 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 0 to 113° F / 0 to 45° C
Heat protection: Heat shield
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-2C Cube Logger can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.
Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-394 UV-2C-T Cube Logger Radiometer

M007-395 UV-2C-T Cube Logger Radiometer

M007-396 UV-2C-T Cube Logger Radiometer

M007-397 UV-2C-T Cube Logger Radiometer

M007-398 UV-2C-T Cube Logger Radiometer

M007-399 UV-2C-T Cube Logger Radiometer

M007-394 UV-2C-T Cube Logger Radiometer Datasheet


MICROLOG II »

The UV-1400 Radiometer + Dosimeter is a self-contained, high quality UV measuring instrument.

+ UV-intensity mW/cm2
+ UV-dose mJ/cm2
+ Permanent or „triggered“ measuring mode*
+ 120 sec recording readiness phase*
+ 120 sec recording cycle*

The UV-1400 Radiometer + Dosimeter is a self-contained, high quality UV measuring instrument. It is designed to measure, record and display peak UV intensity and UV dosage in the UV curing process. In the standard version it is equipped with one UV sensor for the measuring of:

Full UV spectral area 250 – 410 nm

Due to its UV sensor and the integrated microprocessor the UV-1400 Radiometer + Dosimeter can measure, record and display the peak UV-intensity of the total UV spectrum (mW/cm2). Additionally, it is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated as the total Integral of UV-dosage over the full UV spectral bands. The UV-1400 Radiometer + Dosimeter features a selectable „triggered mode“, i.e. the 120 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm². The sensor is on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

TECHNICAL DATA
Spectral range: UV 250 – 410 nm (Standard)
Max. Power Input 0 to 5,000 mW/cm2
Display: LCD, 2x16 digits
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 120 sec.
Readiness phase: 120 sec.
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: Æ 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17,5 ounce (500 g)
Operating temperature: 32 to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-1400 Radiometer + Dosimeter can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration

M007-400 MICROLOG II RADIOMETER AND DOSIMETER

M007-401 MICROLOG II RADIOMETER AND DOSIMETER

M007-400 MICROLOG II RADIOMETER AND DOSIMETER DATASHEET


UV-1000 COLOR RADIOMETER AND DOSIMETER »

The UV-1000 COLOR RADI0METER AND DOSIMETER is a self-contained, high quality UV measuring instrument.

+ UV-intensity mW/cm2
+ UV-dose mJ/cm2
+ Big colour graphic display
+ Numerical and graphical display
+ Permanent or „triggered“ measuring mode*

It is designed to measure and record UV intensity and UV dosage in the UV curing process. Measuring results are indicated both, graphically and numerically on a big colour display In the standard version it is equipped with one UV sensor for the measuring of:

Full UV spectral area 230 – 410 nm

Due to its UV sensor and the integrated microprocessor the UV-1000 Colour Radiometer + Dosimeter can measure, record and display the peak UV-intensity of the total UV spectrum (mW/cm2). Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated as the total Integral of UV-dosage over the full UV spectral bands. Optionally it is available with an extra sensor for measuring temperatures from 32 to 230° F / 0 to 110° C. This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The sensor is on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT colour display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

SD Memory card used to store data replaces the USB comport. The measuring data is stored directly to the inserted SD card and a circumstancial data transfer to a PC is not necesary after each measuring cycle. The evaluation software has been modified and is more user-friendly compared to earlier versions.

TECHNICAL DATA
Spectral range: UV 230 – 410 nm (Standard)
Max. Power Input 0 to 5,000 mW/cm2
Display: TFT Colour Display, 45 x 34 mm (1.75” x 1.3”)
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: Æ 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17,5 ounce (500 g)
Operating temperature: 32 to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot


While on the conveyer belt, the UV-1000 Colour Radiometer + Dosimeter can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-417 UV-1000 RADIOMETER AND DOSIMETER

M007-418 UV-1000 RADIOMETER AND DOSIMETER

M007-419 UV-1000 RADIOMETER AND DOSIMETER

M007-420 UV-1000 RADIOMETER AND DOSIMETER

M007-421 UV-1000 RADIOMETER AND DOSIMETER

M007-417 UV-1000 RADIOMETER AND DOSIMETER DATASHEET


UV-1300 COLOR RADIOMETER AND DOSIMETER PLUS TEMPERATURE »

The UV-1300 COLOR RADI0METER AND DOSIMETER PLUS TEMPERATURE is a self-contained, high quality UV measuring instrument.

+ UV-A intensity mW/cm² + UV-A dose mJ/cm²
+ UV-B intensity mW/cm² + UV-B dose mJ/cm²
+ UV-C intensity mW/cm² + UV-C dose mJ/cm²
+ *UV-V intensity mW/cm² + UV-V dose mJ/cm²
+ Full UV intensity mW/cm² + Full UV dose mJ/cm²
+ Big color graphic display
+ Numerical and graphical display
+ Permanent or „triggered“ measuring mode*

It is designed to measure and record UV intensity and UV dosage in the UV curing process. Measuring results are indicated both, graphically and numerically on a big colour display. It is equipped with three different UV sensors for the individual measuring of

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm*
UV - 230 – 410 nm

With these three different UV-bands most of the measuring requirements of UV curing applications can be covered. Due to its three different UV sensors and the integrated microprocessor the UV-1300 Colour Radiometer + Dosimeter can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV energy. Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B and UV-C or UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. Optionally it is available with an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C.

*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm²

The three sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT colour display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

The UV-1300 Color ComPort Radiometer + Dosimeter comes with a SD Memory card used to store data replaces the USB comport. The measuring data is stored directly to the inserted SD card and a circumstancial data transfer to a PC is not necesary after each measuring cycle. The evaluation software has been modified and is more user-friendly compared to earlier versions.

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm or (UV-V 395 – 445 nm)*
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: TFT Colour Display, 45 x 34 mm (1.75” x 1.3”)
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: Æ 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° Celsius
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot

While on the conveyer belt, the UV-1300 Colour Radiometer + Dosimeter can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-422 UV-1300 COLOUR RADIOMETER AND DOSIMETER PLUS TEMPERATURE

M007-423 UV-1300 COLOUR RADIOMETER AND DOSIMETER PLUS TEMPERATURE

M007-422 UV-1300 COLOUR RADIOMETER AND DOSIMETER PLUS TEMPERATURE DATASHEET


UV 1010 COLOR RADIOMETER AND DOSIMETER PLUS TEMPERATUREM+DOSIMTR+T »

The UV-1010 COLOR RADI0METER AND DOSIMETER PLUS TEMPERATURE is a self-contained, high quality UV measuring instrument.

+ UV-intensity mW/cm2
+ UV-dose mJ/cm2
+ Temperature measuring °C/°F
+ Big color graphic display
+ Numerical and graphical display
+ Permanent or „triggered“ measuring mode*

It is designed to measure and record UV intensity, UV dosage and temperature in the UV curing process. Measuring results are indicated both, graphically and numerically on a big color display In the standard version it is equipped with one UV sensor for the measuring of:

Full UV spectral area 230 – 410 nm
Temp 32 to 230° F / 0 to 110° C

Due to its UV sensor and the integrated microprocessor the UV-1010 Color Radiometer + Dosimeter can measure, record and display the peak UV-intensity of the total UV spectrum (mW/cm2). Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated as the total Integral of UV-dosage over the full UV spectral bands. With an extra sensor for measuring temperatures from 32 to 230° F / 0 to 110° C.

SD Memory card used to store data replaces the USB comport. The measuring data is stored directly to the inserted SD card and a circumstancial data transfer to a PC is not necesary after each measuring cycle. The evaluation software has been modified and is more user-friendly compared to earlier versions.

*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm². The sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT color display A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. As an option, this instrument is available with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ/cm2)

TECHINICAL DATA
Spectral range: UV 230 – 410 nm (Standard)
Max. Power Input 0 to 5,000 mW/cm2
Display: TFT Color Display, 45 x 34 mm (1.75” x 1.3”)
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: Æ 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17,5 ounce (500 g)
Operating temperature: 32 to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot

While on the conveyer belt, the UV-1010 Color Radiometer + Dosimeter can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-424 UV-1011 UV-V COLOUR RADIOMETER AND DOSIMETER PLUS TEMPERATURE

M007-425 UV-1012 UV-A COLOUR RADIOMETER AND DOSIMETER PLUS TEMPERATURE

M007-426 UV-1011 UV COLOUR RADIOMETER AND DOSIMETER PLUS TEMPERATURE

M007-427 UV-1014 UV-B COLOUR RADIOMETER AND DOSIMETER PLUS TEMPERATURE

M007-428 UV-1015 UV-C COLOUR RADIOMETER AND DOSIMETER PLUS TEMPERATURE

M007-424 UV+1010 RADIOMETER AND DOSIMETER Datasheet


UV-1310 COLOR RADIOMETER AND DOSIMETER PLUS UV AND TEMPERATURE »

The UV-1310 COLOR RADI0METER AND DOSIMETER PLUS UV AND TEMPERATURE is a self-contained, high quality UV measuring instrument.

+ UV-A intensity mW/cm² + UV-A dose mJ/cm²
+ UV-B intensity mW/cm² + UV-B dose mJ/cm²
+ UV-C intensity mW/cm² + UV-C dose mJ/cm²
+ *UV-V intensity mW/cm² + UV-V dose mJ/cm²
+ Full UV intensity mW/cm² + Full UV dose mJ/cm²
+ Temperature measuring °C/°F
+ Big color graphic display
+ Numerical and graphical display
+ Permanent or „triggered“ measuring mode*

It is designed to measure and record UV intensity, UV dosage and temperature in the UV curing process. Measuring results are indicated both, graphically and numerically on a big color display. It is equipped with three different UV sensors and one temperature sensor for the individual measuring of

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm*
UV - 230 – 410 nm

With these three different UV-bands most of the measuring requirements of UV curing applications can be covered. Due to its three different UV sensors and the integrated microprocessor the UV-1310 Color Radiometer + Dosimeter can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV energy. Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B and UV-C or UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. Additionally it is equipped with an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C.

*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The four sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT color display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

The UV-1310 Color ComPort Radiometer + Dosimeter comes with a SD Memory card used to store data replaces the USB comport. The measuring data is stored directly to the inserted SD card and a circumstancial data transfer to a PC is not necesary after each measuring cycle. The evaluation software has been modified and is more user-friendly compared to earlier versions.


TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm or (UV-V 395 – 445 nm)*
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: TFT Color Display, 45 x 34 mm (1.75” x 1.3”)
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: Æ 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° Celsius
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot

While on the conveyer belt, the UV-1310 Color Radiometer + Dosimeter can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-429 UV-1310 COLOUR RADIOMETER & DOSIMETER PLUS UV & TEMPERATURE

M007-430 UV-1311 COLOUR RADIOMETER & DOSIMETER PLUS UVABC & TEMPERATURE

M007-429 UV-1310 COLOUR RADIOMETER & DOSIMETER PLUS UV & TEMPERATURE


UV-1210 COLOR RADIOMETER AND DOSIMETER »

The UV-1210 COLOR RADI0METER AND DOSIMETER is a self-contained, high quality UV measuring instrument.

+ Choice of a combination of two different spectral ranges:
+ UV-A intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-B intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-C intensity mW/cm2 + UV-A dose mJ/cm2
+ UV-V intensity mW/cm2 + UV-V dose mJ/cm2
+ Big colour graphic display
+ Numerical and graphical display
+ Permanent or „triggered“ measuring mode*

It is designed to measure and record UV intensity and UV dosage in the UV curing process. Measuring results are indicated both, graphically and numerically on a big colour display. It is equipped with two different UV sensors for the individual measuring of a combination of either:

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV - 230 – 410 nm

The UV-1200 Color ComPort Radiometer + Dosimeter comes with a SD Memory card used to store data replaces the USB comport. The measuring data is stored directly to the inserted SD card and a circumstancial data transfer to a PC is not necesary after each measuring cycle. The evaluation software has been modified and is more user-friendly compared to earlier versions.

With these two different UV-bands many of the measuring requirements of UV curing applications can be covered. Due to its two different UV sensors and the integrated microprocessor the UV-1200 Colour Radiometer + Dosimeter can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV energy. Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B and UV-C or UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. Optionally it is available with an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C.

*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The two sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT colour display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. As an option, the UV-1200 Colour Radiometer + Dosimeter is available with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2) and (°C/°F)

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm, UV-V 395 – 445 nm
UV-B 280 – 315 nm, UV-C 230 – 280 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: TFT Colour Display, 45 x 34 mm (1.75” x 1.3”)
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: Æ 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° Celsius
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot

While on the conveyer belt, the UV-1200 Colour Radiometer + Dosimeter can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-438 UV-1211 COLOR RADIOMETER AND DOSIMETER

M007-439 UV-1212 COLOR RADIOMETER AND DOSIMETER

M007-440 UV-1213 COLOR RADIOMETER AND DOSIMETER

M007-441 UV-1214 COLOR RADIOMETER AND DOSIMETER

M007-442 UV-1215 COLOR RADIOMETER AND DOSIMETER

M007-443 UV-1216 COLOR RADIOMETER AND DOSIMETER

M007-444 UV-1217 COLOR RADIOMETER AND DOSIMETER



M007-438 UV-1211 COLOR RADIOMETER AND DOSIMETER DATASHEET




UV-1400 COLOR RADIOMETER AND DOSIMETER »

The UV-1400 COLOR RADI0METER AND DOSIMETER is a self-contained, high quality UV measuring instrument.

+ UV-A intensity mW/cm² + UV-A dose mJ/cm²
+ UV-B intensity mW/cm² + UV-B dose mJ/cm²
+ UV-C intensity mW/cm² + UV-C dose mJ/cm²
+ UV-V intensity mW/cm² + UV-V dose mJ/cm²
+ Full UV intensity mW/cm² + Full UV dose mJ/cm²
+ Big color graphic display
+ Numerical and graphical display
+ Permanent or "triggered“ measuring mode*

It is designed to measure and record UV intensity and UV dosage in the UV curing process. Measuring results are indicated both, graphically and numerically on a big color display. It is equipped with four different UV sensors for the individual measuring of:

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV - 230 – 410 nm

With these four different UV-bands most of the measuring requirements of UV curing applications can be covered. Due to its three different UV sensors and the integrated microprocessor the UV-1400 Color Radiometer + Dosimeter can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV energy. Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B, UV-C and UV-V) individually and as total Integral of UV-dosage over the full UV-range. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band.

*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The four sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT color display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

The UV-1400 Color ComPort Radiometer + Dosimeter comes with a SD Memory card used to store data replaces the USB comport. The measuring data is stored directly to the inserted SD card and a circumstancial data transfer to a PC is not necesary after each measuring cycle. The evaluation software has been modified and is more user-friendly compared to earlier versions.


TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV 230 – 410 nm

Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: TFT Color Display, 45 x 34 mm (1.75” x 1.3”)
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: Æ 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° Celsius
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot

While on the conveyer belt, the UV-1400 Color Radiometer + Dosimeter can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-445 UV-1400 COLOUR RADIOMETER & DOSIMETER

M007-445 UV-1400 COLOUR RADIOMETER & DOSIMETER DATASHEET




UV-1050 COLOR COMPORT RADIOMETER AND DOSIMETER »

The UV-1050 COLOR COMPORT RADI0METER AND DOSIMETER is a self-contained, high quality UV measuring instrument.

+ UV-intensity mW/cm2
+ UV-dose mJ/cm2
+ Big color graphic display
+ Numerical and graphical display
+ Permanent or „triggered“ measuring mode*
+ USB ComPort

It is designed to measure and record UV intensity and UV dosage in the UV curing process. Measuring results are indicated both, graphically and numerically on a big color display. In the standard version it is equipped with one UV sensor for the measuring of:

Full UV spectral area 230 – 410 nm

Due to its UV sensor and the integrated microprocessor the UV-1050 Color ComPort Radiometer + Dosimeter can measure, record and display the peak UV-intensity of the total UV spectrum (mW/cm2). Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated as the total Integral of UV-dosage over the full UV spectral bands. Optionally it is available with an extra sensor for measuring temperatures from 32 to 230° F / 0 to 110° C.

*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm². The sensor is on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT color display A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

The UV-1050 Color ComPort Radiometer + Dosimeter comes with a SD Memory card used to store data replaces the USB comport. The measuring data is stored directly to the inserted SD card and a circumstancial data transfer to a PC is not necesary after each measuring cycle. The evaluation software has been modified and is more user-friendly compared to earlier versions. The UV-1050 Color ComPort Radiometer + Dosimeter is available in five different measuring ranges:

Color ComPort Radiometer + Dosimeter Diazo 350 – 460 nm
Color ComPort Radiometer + Dosimeter UV-A 315 – 400 nm
Color ComPort Radiometer + Dosimeter UV 230 – 410 nm
Color ComPort Radiometer + Dosimeter UV-B 280 – 315 nm
Color ComPort Radiometer + Dosimeter UV-C 230 – 280 nm

TECHNICAL DATA
Spectral range: UV 230 – 410 nm (Standard)
Max. Power Input 0 to 5,000 mW/cm2
Display: TFT Color Display, 45 x 34 mm (1.75” x 1.3”)
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: ??5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17,5 ounce (500 g)
Operating temperature: 32 to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot

While on the conveyer belt, the UV-1050 Color ComPort Radiometer + Dosimeter can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN

M007-446 UV-1051 COLOUR COMPORT RADIOMETER AND DOSIMETER

M007-447 UV-1052 COLOUR COMPORT RADIOMETER AND DOSIMETER

M007-448 UV-1053 COLOUR COMPORT RADIOMETER AND DOSIMETER

M007-449 UV-1054 COLOUR COMPORT RADIOMETER AND DOSIMETER

M007-450 UV-1055 COLOUR COMPORT RADIOMETER AND DOSIMETER



M007-446 UV-1050 COLOUR COMPORT RADIOMETER AND DOSIMETER DATASHEET




UV-1350 COLOR COMPORT RADIOMETER AND DOSIMETER »

The UV-1350 COLOR COMPORT RADI0METER AND DOSIMETER is a self-contained, high quality UV measuring instrument.

+ UV-A intensity mW/cm² + UV-A dose mJ/cm²
+ UV-B intensity mW/cm² + UV-B dose mJ/cm²
+ UV-C intensity mW/cm² + UV-C dose mJ/cm²
+ *UV-V intensity mW/cm² + UV-V dose mJ/cm²
+ Full UV intensity mW/cm² + Full UV dose mJ/cm²
+ Big color graphic display
+ Numerical and graphical display
+ Permanent or "triggered“ measuring mode*
+ USB ComPort and PC evaluation software

It is designed to measure and record UV intensity and UV dosage in the UV curing process. Measuring results are indicated both, graphically and numerically on a big colour display. It is equipped with three different UV sensors for the individual measuring of:

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm*
UV - 230 – 410 nm

With these three different UV-bands most of the measuring requirements of UV curing applications can be covered. Due to its three different UV sensors and the integrated microprocessor the UV-1350 Colour ComPort Radiometer + Dosimeter can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV energy.

Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the
time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B
and UV-C or UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to
determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at
what UV-band. Optionally it is available with an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C.
*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120
second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².
The three sensors are on the back of the unit which also serves as a heat shield. After completion of the
measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on
the built in 45 x 34 mm (1.75” x 1.3”) TFT colour display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.
The UV-1250 Color ComPort Radiometer + Dosimeter comes with a SD Memory card used to store data replaces the USB comport. The measuring data is stored directly to the inserted SD card and a circumstancial data transfer to a PC is not necesary after each measuring cycle. The evaluation software has been modified and is more user-friendly compared to earlier versions.

UV-1350 Colour ComPort Radiometer + Dosimeter UV-A, UV-B, UV-C
UV-1351 Colour ComPort Radiometer + Dosimeter UV-A, UV-B, UV-V

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: TFT Colour Display, 45 x 34 mm (1.75” x 1.3”)
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° Celsius
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot

While on the conveyer belt, the UV-1350 Colour ComPort Radiometer + Dosimeter can withstand max.
230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.
Because of uneven radiation distribution of the UV light source and different type of construction of the
measuring devices by different manufacturers, different readings may appear under the same
measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per
year. Re-calibration will also be necessary after change of battery.

M007-451 UV-1350 COLOUR COMPORT RADIOMETER AND DOSIMETER

M007-452 UV-1351 COLOUR COMPORT RADIOMETER AND DOSIMETER



M007-451 UV-1350 COLOUR COMPORT RADIOMETER AND DOSIMETER DATASHEET






UV-1060 COLOR COMPORT RADIOMETER AND DOSIMETER »

The UV-1060 COLOR COMPORT RADI0METER AND DOSIMETER is a self-contained, high quality UV measuring instrument.

+ UV-intensity mW/cm2
+ UV-dose mJ/cm2
+ Temperature measuring °C/°F
+ Big colour graphic display
+ Numerical and graphical display
+ Permanent or „triggered“ measuring mode*
+ USB ComPort

It is designed to measure and record UV intensity, UV dosage and temperature in the UV
curing process. Measuring results are indicated both, graphically and numerically on a big colour display. In the standard version it is equipped with one UV sensor for the measuring of:

Full UV spectral area 230 – 410 nm
Temp 32 to 230° F / 0 to 110° C

Due to its UV sensor and the integrated microprocessor the UV-1060 Colour ComPort Radiometer +
Dosimeter can measure, record and display the peak UV-intensity of the total UV spectrum (mW/cm2).
Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the
time of exposure of one measuring cycle. The UV-dosage is calculated as the total Integral of UV-dosage
over the full UV spectral bands. With an extra sensor for measuring temperatures from 32 to 230° F / 0 to 110° C.
*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120
second readiness phase not before the incident UV-intensity exceeds 2 mW/cm². The sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT colour display
A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

The UV-1060 Color ComPort Radiometer + Dosimeter comes with a SD Memory card used to store data replaces the USB comport. The measuring data is stored directly to the inserted SD card and a circumstancial data transfer to a PC is not necesary after each measuring cycle. The evaluation software has been modified and is more user-friendly compared to earlier versions.
The UV-1060 Colour ComPort Radiometer + Dosimeter is available in five different measuring ranges:

Color ComPort Radiometer + Dosimeter Diazo 350 – 460 nm
Color ComPort Radiometer + Dosimeter UV-A 315 – 400 nm
Color ComPort Radiometer + Dosimeter UV 230 – 410 nm
Color ComPort Radiometer + Dosimeter UV-B 280 – 315 nm
Color ComPort Radiometer + Dosimeter UV-C 230 – 280 nm

TECHNICAL DATA
Spectral range: UV 230 – 410 nm (Standard)
Max. Power Input 0 to 5,000 mW/cm2
Display: TFT Colour Display, 45 x 34 mm (1.75” x 1.3”)
Display range: 0 to 36,000 mJ/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17,5 ounce (500 g)
Operating temperature: 32 to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot

While on the conveyer belt, the UV-1060 Colour ComPort Radiometer + Dosimeter can withstand max.
230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.
Because of uneven radiation distribution of the UV light source and different type of construction of the
measuring devices by different manufacturers, different readings may appear under the same
measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per
year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN
EN ISO / IEC 17025 with certificate

M007-453 UV-1061 COLOR COMPORT RADIOMETER + DOSIMETER

M007-454 UV-1062 COLOR COMPORT RADIOMETER + DOSIMETER

M007-455 UV-1063 COLOR COMPORT RADIOMETER + DOSIMETER

M007-456 UV-1064 COLOR COMPORT RADIOMETER + DOSIMETER

M007-457 UV-1065 COLOR COMPORT RADIOMETER + DOSIMETER

M007-453 UV-1060 COLOR COMPORT RADIOMETER + DOSIMETER DATASHEET


UV-1360 COLOR COMPORT RADIOMETER AND DOSIMETER »

The UV-1360 COLOR COMPORT RADI0METER AND DOSIMETER is a self-contained, high quality UV measuring
instrument.

+ UV-A intensity mW/cm² + UV-A dose mJ/cm²
+ UV-B intensity mW/cm² + UV-B dose mJ/cm²
+ UV-C intensity mW/cm² + UV-C dose mJ/cm²
+ *UV-V intensity mW/cm² + UV-V dose mJ/cm²
+ Full UV intensity mW/cm² + Full UV dose mJ/cm²
+ Temperature measuring °C / °F
+ Big color graphic display
+ Numerical and graphical display
+ Permanent or „triggered“ measuring mode*
+ USB ComPort and PC evaluation software

It is designed to measure and record UV intensity, UV dosage and temperature in the UV
curing process. Measuring results are indicated both, graphically and numerically on a big colour display.
It is equipped with three different UV sensors and one temperature sensor for the individual measuring of:

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm*
UV - 230 – 410 nm
Temp 32 to 230° F / 0 to 110° C

With these three different UV-bands most of the measuring requirements of UV curing applications can be
covered. Due to its three different UV sensors and the integrated microprocessor the UV-1360 Colour ComPort
Radiometer + Dosimeter can measure, record and display the peak of the UV-intensity (mW/cm2) for
each UV-band individually plus the peak of total UV energy.

Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the
time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B
and UV-C or UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to
determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at
what UV-band.

Additionally it is equipped with an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C.
*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120
second readiness phase not before the incident UV-intensity exceeds 2 mW/cm². The four sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT colour display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

The UV-1360 Color ComPort Radiometer + Dosimeter comes with a SD Memory card used to store data replaces the USB comport. The measuring data is stored directly to the inserted SD card and a circumstancial data transfer to a PC is not necesary after each measuring cycle. The evaluation software has been modified and is more user-friendly compared to earlier versions.

UV-1360 Colour ComPort Radiometer + Dosimeter UV-A, UV-B, UV-C + temperature
UV-1361 Colour ComPort Radiometer + Dosimeter UV-A, UV-B, UV-V + temperature

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: TFT Colour Display, 45 x 34 mm (1.75” x 1.3”)
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° Celsius
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot

While on the conveyer belt, the UV-1360 Colour ComPort Radiometer + Dosimeter can withstand max.
230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.
Because of uneven radiation distribution of the UV light source and different type of construction of the
measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per
year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN
EN ISO / IEC 17025 with certificate

M007-458 UV-1360 COLOR COMPORT RADIOMETER AND DOSIMETER

M007-459 UV-1361 COLOR COMPORT RADIOMETER AND DOSIMETER

M007-458 UV-1360 COLOR COMPORT RADIOMETER+DOSIMETER DATASHEET


UV-1250 COLOR COMPORT RADI0METER AND DOSIMETER »

The UV-1250 COLOR COMPORT RADI0METER AND DOSIMETER is a self-contained, high quality UV measuring instrument.

+ Choice of a combination of two different spectral ranges:
+ UV-A intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-B intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-C intensity mW/cm2 + UV-A dose mJ/cm2
+ UV-V intensity mW/cm2 + UV-V dose mJ/cm2
+ Big COLOR graphic display
+ Numerical and graphical display
+ Permanent or triggered“ measuring mode*
+ USB ComPort and PC evaluation software

The UV-1250 COLOR ComPort Radiometer + Dosimeter is a self-contained, high quality UV measuring
instrument. It is designed to measure and record UV intensity and UV dosage in the UV curing process.
Measuring results are indicated both, graphically and numerically on a big COLOR display.
It is equipped with two different UV sensors for the individual measuring of a combination of either:

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV - 230 – 410 nm

The UV-1250 Color ComPort Radiometer + Dosimeter comes with a SD Memory card used to store data replaces the USB comport. The measuring data is stored directly to the inserted SD card and a circumstancial data transfer to a PC is not necesary after each measuring cycle. The evaluation software has been modified and is more user-friendly compared to earlier versions.

With these two different UV-bands many of the measuring requirements of UV curing applications can be
covered. Due to its two different UV sensors and the integrated microprocessor the UV-1250 COLOR Radiometer +Dosimeter can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV energy.

Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time
of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B and UV-C or
UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not
only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band.
Optionally it is available with an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C.

*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120
second readiness phase not before the incident UV-intensity exceeds 2 mW/cm². The two sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT COLOR display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.The following versions are available:

COLOR ComPort Radiometer + Dosimeter UV-A + UV-V
COLOR ComPort Radiometer + Dosimeter UV-A + UV-B
COLOR ComPort Radiometer + Dosimeter UV + UV-A
COLOR ComPort Radiometer + Dosimeter UV + UV-B
COLOR ComPort Radiometer + Dosimeter UV + UV-V
COLOR ComPort Radiometer + Dosimeter UV-B + UV-V
COLOR ComPort Radiometer + Dosimeter UV-C + UV-V

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-V 395 – 445 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: TFT COLOR Display, 45 x 34 mm (1.75” x 1.3”)
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° Celsius
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot

While on the conveyer belt, the UV-1250 COLOR ComPort Radiometer + Dosimeter can withstand max.
230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.
Because of uneven radiation distribution of the UV light source and different type of construction of the
measuring devices by different manufacturers, different readings may appear under the same
measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per
year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN
EN ISO / IEC 17025 with certificate.

M0007-460 UV-1251 COLOUR COMPORT RADIOMETER & DOSIMETER

M0007-461 UV-1252 COLOUR COMPORT RADIOMETER & DOSIMETER

M0007-462 UV-1253 COLOUR COMPORT RADIOMETER & DOSIMETER

M0007-463 UV-1254 COLOUR COMPORT RADIOMETER & DOSIMETER

M0007-464 UV-1255 COLOUR COMPORT RADIOMETER & DOSIMETER

M0007-465 UV-1256 COLOUR COMPORT RADIOMETER & DOSIMETER

M0007-466 UV-1257 COLOUR COMPORT RADIOMETER & DOSIMETER

M0007-460 UV-1251 COLOUR COMPORT RADIOMETER & DOSIMETER DATASHEET


UV-1260 COLOR COMPORT RADIOMETER AND DOSIMETER »

The UV-1260 COLOR COMPORT RADI0METER AND DOSIMETER is a self-contained, high quality UV measuring instrument.

+ Choice of a combination of two different spectral ranges:
+ UV-A intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-B intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-C intensity mW/cm2 + UV-A dose mJ/cm2
+ UV-V intensity mW/cm2 + UV-V dose mJ/cm2
+ Temperature measuring °C/°F
+ Big COLOR graphic display
+ Numerical and graphical display
+ Permanent or „triggered“ measuring mode*
+ USB ComPort and PC evaluation software

It is designed to measure and record UV intensity, UV dosage and temperature in the UV curing
process. Measuring results are indicated both, graphically and numerically on a big COLOR display.
It is equipped with two different UV sensors for the individual measuring of a combination of either:

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV - 230 – 410 nm

With these two different UV-bands many of the measuring requirements of UV curing applications can be covered.
Due to its two different UV sensors and the integrated microprocessor the UV-1260 COLOR Radiometer +
Dosimeter can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band
individually plus the peak of total UV energy.

Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time
of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B and UV-C or
UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not
only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band.
With an extra sensor for measuring temperatures from 0 to 230° F / 0 to 110° C.

*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120
second readiness phase not before the incident UV-intensity exceeds 2 mW/cm². The three sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT COLOR display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

The UV-1260 Color ComPort Radiometer + Dosimeter comes with a SD Memory card used to store data replaces the USB comport. The measuring data is stored directly to the inserted SD card and a circumstancial data transfer to a PC is not necesary after each measuring cycle. The evaluation software has been modified and is more user-friendly compared to earlier versions.
The following versions are available:

COLOR ComPort Radiometer + Dosimeter UV-A + UV-V
COLOR ComPort Radiometer + Dosimeter UV-A + UV-B
COLOR ComPort Radiometer + Dosimeter UV + UV-A
COLOR ComPort Radiometer + Dosimeter UV + UV-B
COLOR ComPort Radiometer + Dosimeter UV + UV-V
COLOR ComPort Radiometer + Dosimeter UV-B + UV-V
COLOR ComPort Radiometer + Dosimeter UV-C + UV-V

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-V 395 – 445 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: TFT COLOR Display, 45 x 34 mm (1.75” x 1.3”)
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° Celsius
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot

While on the conveyer belt, the UV-1260 COLOR ComPort Radiometer + Dosimeter can withstand max.
230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.
Because of uneven radiation distribution of the UV light source and different type of construction of the
measuring devices by different manufacturers, different readings may appear under the same
measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per
year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN
EN ISO / IEC 17025 with certificate

M007-467 UV-1261 COLOUR COMPORT RADIOMETER  AND DOSIMETER

M007-468 UV-1262 COLOUR COMPORT RADIOMETER  AND DOSIMETER

M007-469 UV-1263 COLOUR COMPORT RADIOMETER  AND DOSIMETER

M007-470 UV-1264 COLOUR COMPORT RADIOMETER  AND DOSIMETER

M007-471 UV-1265 COLOUR COMPORT RADIOMETER  AND DOSIMETER

M007-472 UV-1266 COLOUR COMPORT RADIOMETER  AND DOSIMETER

M007-473 UV-1267 COLOUR COMPORT RADIOMETER  AND DOSIMETER

M007-467 UV-1261 COLOUR COMPORT RADIOMETER  AND DOSIMETER DATASHEET


UV-1450 COLOR COMPORT RADIOMETER AND DOSIMETER »

The UV-1450 COLOR COMPORT RADI0METER AND DOSIMETER is a self-contained, high quality UV measuring instrument.

+ UV-A intensity mW/cm² + UV-A dose mJ/cm²
+ UV-B intensity mW/cm² + UV-B dose mJ/cm²
+ UV-C intensity mW/cm² + UV-C dose mJ/cm²
+ UV-V intensity mW/cm² + UV-V dose mJ/cm²
+ Full UV intensity mW/cm² + Full UV dose mJ/cm²
+ Big COLOR graphic display
+ Numerical and graphical display
+ Permanent or „triggered“ measuring mode*
+ USB ComPort and PC evaluation software
It is designed to measure and record UV intensity and UV dosage in the UV curing process. Measuring results are indicated both, graphically and numerically on a big COLOR display. It is equipped with four different UV sensors for the individual measuring of:

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV - 230 – 410 nm

With these four different UV-bands most of the measuring requirements of UV curing applications can be covered. Due to its three different UV sensors and the integrated microprocessor the UV-1450 COLOR ComPort Radiometer + Dosimeter can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV energy.

Additionally, this instrument is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B, UV-C and UV-V) individually and as total Integral of UV-dosage over the full UV-range. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band.
*This instrument features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm². The four sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle the measuring results are instantly displayed numerically and graphically auto-scaled on the built in 45 x 34 mm (1.75” x 1.3”) TFT COLOR display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.
The UV-1450 COLOR ComPort Radiometer + Dosimeter is equipped with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2) and (°C/°F)

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: TFT COLOR Display, 45 x 34 mm (1.75” x 1.3”)
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° Celsius
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
Equipped with re-chargable batteries and charging unit
SD memory card slot


While on the conveyer belt, the UV-1450 COLOR ComPort Radiometer + Dosimeter can withstand max.
230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.

Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-474 UV-1450 COLOUR COMPORT RADIOMETER AND DOSIMETER

M007-474 UV-1450 COLOUR COMPORT RADIOMETER AND DOSIMETER DATASHEET


UV-2C MICROPROCESSOR INTERGRATOR »

The UV-2C MICROPROCESSOR INTEGRATOR is an economical, self-contained, high quality UV measuring instrument. It is designed to measure, record and display peak UV intensity and UV dosage in the UV curing process.

+ Choice of a combination of two different spectral ranges:
+ UV-A intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-B intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-C intensity mW/cm2 + UV-A dose mJ/cm2
+ UV-V intensity mW/cm2 + UV-V dose mJ/cm2
+ Permanent or triggered“ measuring mode*
+ Re-chargeable accu cells with charger

It is equipped with two different UV sensors for the individual measuring of a combination of either:

UV-C 230 – 280 nm
UV-B 280 – 315 nm
UV-A 315 – 400 nm
UV-V 395 – 445 nm
UV 250 – 410 nm

With two different UV-bands, many of the measuring requirements of UV curing applications can be covered. Due to its two different UV sensors and the integrated microprocessor the UV-2C Microprocessor Integrator can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually. Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B, UV-C or UV-V) individually. This allows to determine not only the UV-energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. Optionally, an extra sensor measures temperatures from 32 to 230° F / 0 to 110° C.
*This Microprocessor Integrator features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The two sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle all measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. As a further option this microprocessor integrator is available with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2) and (°F – option -)

UV-2C Microprocessor Integrator UV-A + UV-V
UV-2C Microprocessor Integrator UV-A + UV-B
UV-2C Microprocessor Integrator UV + UV-A
UV-2C Microprocessor Integrator UV + UV-B
UV-2C Microprocessor Integrator UV + UV-V
UV-2C Microprocessor Integrator UV-B + UV-V
UV-2C Microprocessor Integrator UV-C + UV-V

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm, UV-V 395 – 445 nm , UV-B 280 – 315 nm, UV-C 230 – 280 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2
Display range: 0 to 60,000 mJ/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display: LCD, 2 x 16 digits
Power source: 2 x 3.7 V LiPO Accu
Power consumption: 20 µA
Accu service life: 1,000 re-charging cycles
Dimensions: 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-2C Microprocessor Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

ATTENTION:
1. Please avoid shaking the UV-2C Microprocessor Integrator.
2. Do not expose to excessive heat.
3. UV-light is hazardous to your health. Avoid direct UV-light to your eyes and to your body.

M007-476 UV-2C MICROPROCESSOR INTEGRATOR RADIOMETER

M007-476 UV-2C MICROPROCESSOR INTEGRATOR RADIOMETER

M007-476 UV-2C MICROPROCESSOR INTEGRATOR RADIOMETER

M007-476 UV-2C MICROPROCESSOR INTEGRATOR RADIOMETER

M007-476 UV-2C MICROPROCESSOR INTEGRATOR RADIOMETER

M007-476 UV-2C MICROPROCESSOR INTEGRATOR RADIOMETER

M007-476 UV-2C MICROPROCESSOR INTEGRATOR RADIOMETER

M007-476 UV-2C MICROPROCESSOR INTEGRATOR RADIOMETER


UV-2C-T MICROPROCESSOR INTERGRATOR »

The UV-2C-T MICROPROCESSOR INTERGRATOR is an economical, self-contained, high quality UV measuring instrument. It is designed to measure, record and display peak UV intensity and UV dosage in the UV curing process.

+ Choice of a combination of two different spectral ranges:
+ UV-A intensity mW/cm2 + UV-A dose mJ/cm2
+ UV-B intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-C intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-V intensity mW/cm2 + UV-V dose mJ/cm2
+ Permanent or „triggered“ measuring mode*
+ Temperature measuring °C/°F
+ Re-chargeable accu cells with charger

It is equipped with two different UV sensors for the individual measuring of a combination of either:

UV-C 230 – 280 nm
UV-B 280 – 315 nm
UV-A 315 – 400 nm
UV-V 395 – 445 nm
UV 250 – 410 nm
Temp 32° to 230° F / 0° to 110° Celsius

With two different UV-bands, many of the measuring requirements of UV curing applications can be covered.
Due to its two different UV sensors and the integrated microprocessor the UV-2C-T Microprocessor Integrator can measure, record and display the peak of the UV-energy (mW/cm2) for each UV-band individually. Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B, UV-C or UV-V) individually. This allows to determine not only the UV-energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. Additionally, an extra sensor measures temperatures from 32 to 230° F / 0 to 110° C.

*This Microprocessor Integrator features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The two sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle all measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. As a further option this microprocessor integrator is available with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2) and (°F – option -)

UV-2C-T Microprocessor Integrator UV-A + UV-V + Temp
UV-2C-T Microprocessor Integrator UV-A + UV-B + Temp
UV-2C-T Microprocessor Integrator UV + UV-A + Temp
UV-2C-T Microprocessor Integrator UV + UV-B + Temp
UV-2C-T Microprocessor Integrator UV + UV-V + Temp
UV-2C-T Microprocessor Integrator UV-B + UV-V + Temp
UV-2C-T Microprocessor Integrator UV-C + UV-V + Temp

TECHNICAL DATA
Spectral ranges:
UV-A 315 – 410 nm, UV-V 395 – 445 nm UV-B 280 – 315 nm, UV-C 230 – 280 nm, UV 250 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2
Display range: 0 to 60,000 mJ/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display: LCD, 2 x 16 digits
Power source: 2 x 3.7 V LiPO Accu
Power consumption: 20 µA
Accu service life: 1,000 re-charging cycles
Dimensions: 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-2C-T Microprocessor Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C.
Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

ATTENTION
1.Please avoid shaking the UV-2C-T Microprocessor Integrator.
2.Do not expose to excessive heat.
3.UV-light is hazardous to your health. Avoid direct UV-light to your eyes and to your body.

M007-483 UV-2C-T Microprocessor Integrator Radiometer with Temperature

M007-484 UV-2C-T Microprocessor Integrator Radiometer with Temperature

M007-485 UV-2C-T Microprocessor Integrator Radiometer with Temperature

M007-486 UV-2C-T Microprocessor Integrator Radiometer with Temperature

M007-487 UV-2C-T Microprocessor Integrator Radiometer with Temperature

M007-488 UV-2C-T Microprocessor Integrator Radiometer with Temperature

M007-489 UV-2C-T Microprocessor Integrator Radiometer with Temperature

M007-483 UV-2C-T Microprocessor Integrator Radiometer with Temperature


UV-4C MICROPROCESSOR INTEGRATOR »

The UV-4C MICROPROCESSOR INTEGRATOR is a self-contained, high quality UV measuring instrument. It is designed to measure, record and display peak UV intensity and UV dosage in the UV curing process.

+ UV-A intensity mW/cm² + UV-A dose mJ/cm²
+ UV-B intensity mW/cm² + UV-B dose mJ/cm²
+ UV-C intensity mW/cm² + UV-C dose mJ/cm²
+ UV-V intensity mW/cm² + UV-V dose mJ/cm²
+ Full UV intensity mW/cm² + Full UV dose mJ/cm²
+ Permanent or "triggered“ measuring mode*
+ Re-chargeable accu cells with charger

It is equipped with four different UV sensors for the individual measuring of
UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV - 250 – 410 nm

With these four different UV-bands all of the measuring requirements of UV curing applications can be covered.
Due to its four different UV sensors and the integrated microprocessor the UV-4C can measure, record and display the peak of the UV-energy (mW/cm2) for each UV-band individually plus the peak of total UV energy.
Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UV-B, UV-C and UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band.

The four sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle all measuring results can be scrolled through on the built in 2 x 16 digit LCD display.
A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life.

*This Microprocessor Integrator features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

As an option, this microprocessor integrator is available with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2) and (°C/°F)

TECHNICAL DATA
Spectral ranges:
UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 350 – 460 nm
UV 230 – 410 nm
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: LCD, 2 x 16 digits
Power source: 2 x 3.7 V LiPO Accu
Power consumption: 20 µA
Accu service life: 1,000 re-charging cycles
Dimensions: 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-4C Microprocessor Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-490 UV-4C MICROPROCESSOR INTEGRATOR

M007-490 UV-4C MICROPROCESSOR INTEGRATOR DATASHEET


UV-2C COMPORT MICRO PROCESSOR INTEGRATOR SD »

The UV-2C COMPORT MICRO PROCESSOR INTEGRATOR SD is an economical, self-contained, high quality UV measuring instrument.

+ Choice of a combination of two different spectral ranges:
+ UV-A intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-B intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-C intensity mW/cm2 + UV-A dose mJ/cm2
+ UV-V intensity mW/cm2 + UV-V dose mJ/cm2
+ Permanent or „triggered“ measuring mode*
+ Re-chargeable accu cells with charger
+ SD Memory Card


It is designed to measure, record and display peak UV intensity and UV dosage in the UV curing process. It is equipped with two different UV sensors for the individual measuring of a combination of either:

UV-C 230 – 280 nm
UV-B 280 – 315 nm
UV-A 315 – 400 nm
UV-V 395 – 445 nm
UV 250 – 410 nm

With two different UV-bands, many of the measuring requirements of UV curing applications can be covered. Due to its two different UV sensors and the integrated microprocessor the UV-2C Microprocessor Integrator can measure,record and display the peak of the UV-energy (mW/cm2) for each UV-band individually. Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A and UV-V) individually. This allows to determine not only the UV-energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. Optionally, an extra sensor measures temperatures from 32 to 230° F / 0 to 110° Celsius.

This microprocessor integrator is additionally equipped with an SD Memory Card. All measuring data are stored and can be downloaded to a computer. The special evaluation software allows to show, edit and store a history of the measuring results of the entire measuring cycle as graphic and numeric charts (mW/cm2) and (mJ cm2) and (°C/°F)and (°F – option -)

*This Microprocessor Integrator features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm². The two sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle all measuring results can be scrolled through on the built in 2 x 16 digit LCD display.

A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. Additionally, this microprocessor integrator is available with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2) and (°F – option -)

TECHNICAL DATA
Spectral ranges:
UV-C 230 – 280 nm
UV-B 280 – 315 nm
UV-A 315 – 400 nm
UV-V 395 – 445 nm
UV 250 – 410 nm

Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2
Display range: 0 to 60,000 mJ/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec
Display: LCD, 2 x 16 digits
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: Æ 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %


While on the conveyer belt, the UV-2C ComPort Microprocessor Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.


CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.


ATTENTION
1. Please avoid shaking the UV-2C ComPort Microprocessor Integrator.
2. Do not expose to excessive heat.
3. UV-light is hazardous to your health. Avoid direct UV-light to your eyes and to your body.

M007-491 UV-2C COMPORT MICRO PROCESSOR INTEGRATOR SD RADIOMETER

M007-492 UV-2C COMPORT MICRO PROCESSOR INTEGRATOR SD RADIOMETER

M007-493 UV-2C COMPORT MICRO PROCESSOR INTEGRATOR SD RADIOMETER

M007-494 UV-2C COMPORT MICRO PROCESSOR INTEGRATOR SD RADIOMETER

M007-495 UV-2C COMPORT MICRO PROCESSOR INTEGRATOR SD RADIOMETER

M007-496 UV-2C COMPORT MICRO PROCESSOR INTEGRATOR SD RADIOMETER

M007-497 UV-2C COMPORT MICRO PROCESSOR INTEGRATOR SD RADIOMETER

M007-491 UV-2C COMPORT MICRO PROCESSOR INTEGRATOR SD RADIOMETER DATASHEET


UV-2C-T COMPORT MICRO PROCESSOR INTEGRATOR SD »

The UV-2C-T COMPORT MICRO PROCESSOR INTEGRATOR SD is an economical, self-contained, high quality UV measuring instrument.

+ Choice of a combination of two different spectral ranges:
+ UV-A intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-B intensity mW/cm2 + UV-V dose mJ/cm2
+ UV-C intensity mW/cm2 + UV-A dose mJ/cm2
+ UV-V intensity mW/cm2 + UV-V dose mJ/cm2
+ Temperature °C/°F
+ Permanent or „triggered“ measuring mode*
+ SD Memory Card
+ Graphic chart on computer
+ Re-chargeable accu cells with charger

It is designed to measure, record and display peak UV intensity, UV dosage and temperature in the UV curing process.It is equipped with two different UV sensors and one temperature sensor for the individual measuring of a combination of either:

UV-C 230 – 280 nm
UV-B 280 – 315 nm
UV-A 315 – 400 nm
UV-V 395 – 445 nm
UV 250 – 410 nm

With two different UV-bands, many of the measuring requirements of UV curing applications can be covered. Due to its two different UV sensors and the integrated microprocessor the UV-2C Microprocessor Integrator can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually. Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A and UV-V) individually. This allows to determine not only the UV-energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band. An extra sensor measures temperatures from 32 to 230° F / 0 to 110° Celsius.

*This Microprocessor Integrator features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The three sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle all measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. This microprocessor integrator is additionally equipped with an SD Memory Card. All measuring data are stored and can be downloaded to a computer. The special evaluation software allows to show, edit and store a history of the measuring results of the entire measuring cycle as graphic and numeric charts (mW/cm2) and (mJ cm2) and (°C/°F)and (°F – option -)

UV-2C-T SD Microprocessor Integrator UV-A + UV-V + Temp
UV-2C-T SD Microprocessor Integrator UV-A + UV-B + Temp
UV-2C-T SD Microprocessor Integrator UV + UV-A + Temp
UV-2C-T SD Microprocessor Integrator UV + UV-B + Temp
UV-2C-T SD Microprocessor Integrator UV + UV-V + Temp
UV-2C-T SD Microprocessor Integrator UV-B + UV-V + Temp
UV-2C-T SD Microprocessor Integrator UV-C + UV-V + Temp

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm, UV-B 280 – 315 nm, UV-C 230 – 280 nm, (UV-V 395 – 445 nm), UV 230 – 410 nm
Temperature range: 32 to 230° F / 0 to 110° C
Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: LCD, 2 x 16 digits
Power source: 2 x 3.7 V LiPO Accu
Power consumption: 20 µA
Accu service life: 1,000 re-charging cycles
Dimensions: 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17.5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-2C-T SD Microprocessor Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate.

M007-498 RADIOMETER UV-2C-T CP INTEGRATOR

M007-499 RADIOMETER UV-2C-T COMPORT

M007-500 RADIOMETER UV-2C-T CP INTEGRATOR

M007-501 RADIOMETER UV-2C-T CP INTEGRATOR

M007-502 RADIOMETER UV-2C-T COMPORT

M007-503 RADIOMETER UV-2C-T CP INTEGRATOR

M007-504 RADIOMETER UV-2C-T COMPORT

M007-498 RADIOMETER UV-2C-T CP INTEGRATOR DATASHEET


UV-4C COMPORT MICROPROCESSOR INTEGRATOR »

The UV-4C COMPORT MICROPROCESSOR INTEGRATOR is a self-contained, high quality UV measuring instrument.

It is designed to measure, record and display peak UV intensity, UV dosage in the UV curing process. It is equipped with four different UV sensors for the individual measuring of:

UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 395 – 445 nm
UV - 250 – 410 nm

With these four different UV-bands, all of the measuring requirements of UV curing applications can be covered. Due to its four different UV sensors and the integrated microprocessor the UV-4C ComPort can measure, record and display the peak of the UV-intensity (mW/cm2) for each UV-band individually plus the peak of total UV energy. Additionally, this UV-Integrator is calculating the UV-dosage (mJ/cm2) of the UV energy supplied during the time of exposure of one measuring cycle. The UV-dosage is calculated for each UV-band (UV-A, UVB, UV-C and UV-V) individually and as total Integral of UV-dosage over all three UV-bands. This allows to determine not only the total energy, but also how that energy is delivered, i.e., what intensity and dose at what UV-band.

*This Microprocessor Integrator features a selectable „triggered mode“, i.e. the 30 sec recording cycle starts within a 120 second readiness phase not before the incident UV-intensity exceeds 2 mW/cm².

The four sensors are on the back of the unit which also serves as a heat shield. After completion of the measuring cycle all measuring results can be scrolled through on the built in 2 x 16 digit LCD display. A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. This microprocessor integrator is additionally equipped with an USB ComPort and an evaluation software for downloading the data to a computer to show, edit and store a history of the measuring results of the entire measuring cycle as graphic charts (mW/cm2) and (mJ cm2) and (°C/°F)

TECHNICAL DATA
Spectral ranges: UV-A 315 – 410 nm
UV-B 280 – 315 nm
UV-C 230 – 280 nm
UV-V 350 – 460 nm
UV 230 – 410 nm

Max. Power Input 0 to 5,000 mW/cm2
Measuring range: 0 to 2,000 mW/cm2 or 2,000 to 5,000 mW/cm2
Sampling rate: 0.005 sec (200/sec)
Recording cycle: 30 sec.
Readiness phase: 120 sec.
Display range: 0 to 36,000 mJ/cm2
Display: LCD, 2 x 16 digits
Power source: 2 x long life 3.6 V Lithium Battery
Power consumption: 20 µA
Battery service life: 2,000 measuring cycles
Dimensions: Æ 5.5” (140 mm), height ½” (13 mm)
Weight: approx. 17,5 ounce (500 g)
Operating temperature: 32° to 113° F / 0 to 45° C
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %

While on the conveyer belt, the UV-4C ComPort Microprocessor Integrator can withstand max. 230° F / 110° C for up to 10 seconds. The temperature of the housing should not exceed 113° F / 45° C. Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers, different readings may appear under the same measurement conditions.

CALIBRATION
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Re-calibration will also be necessary after change of battery. PTB traceable calibration acc. to DIN EN ISO / IEC 17025 with certificate

M007-505 UV-4C COMPORT MICROPROCESSOR INTEGRATOR

M007-505 UV-4C COMPORT MICROPROCESSOR INTEGRATOR DATASHEET










08/03/2013 15:31

Adhesives & Epoxies - Bonding Tools - CO2 Cleaning - Thin Film & Thick Film Resistors - Electronic Packages - Dispensing Equipment - Micro Abrasive Systems - Nitrogen Storage Cabinets - Thermal Interface Materials - UV Curing Systems, UV Test Equipment and Accessories - Solderability Test Equipment - Steam Agers - Epak Custom Equipment - Custom Machine Guarding

All Information and images are © copyright of Epak Electronics Ltd and our Principle Companies. No unauthorised duplication. Site map Privacy Policy
